The following table sums up which parameters can be set and the related range settings.
MENU PARAMETER
CH
GR
TUNING
Freq
AF In Gain
AUDIO
High Pass Filter
Mode
Phase
MIC
PTT Mode
RF POWER RF Power
NOISE RED. NRSYS
Led Light
OTHERS
Led Mode
Battery
MTP40 Lite User Manual
MEANING RANGE SETTINGS
Channel 0 ÷ 59
Group 0 ÷ 39 + SYNC GROUP
depends on the MTP40 Lite Model:
Frequency
Gain of the depends on the mic mode setting
audio signal (ex. -40dB ÷ 40dB step of 1 dB)
High Pass filter Flat/60/80/120/170/250/400 Hz
'2 wires'
'2 wires + bias'
MIC type '3 wires'
'2 wires & phantom'
'2 wires + bias & phantom'
Audio signal
0° or 180°
phase
Disable:when the PTT button is pushed, nothing
happen. (the transmitter sends AF+Tone
squelch)
Normal: when the PTT button is pushed, the
It defines how
transmitter send a different RF signal. According
and what
to the receiver configuration the audio can be
information the
enabled/disable on LINE (and/or COM).
transmitter has
Muting: the transmitter doesn't send the audio.
to send
The voice is cut, it doesn't enter to the
microphone
No Data: the transmitter sends neither tone
squelch nor battery data.
High (50 mW ERP) or
RF Power
Low (10 mW ERP)
ENR: Wisycom Extended-NR,noise optimized
Noise reduction
ENC: Wisycom Extended-NC,voice optimized
Power switch
green 0 ÷ 16
brightness
It defines when
the power
None: never
switch led (see
ModPeak: when audio get close to saturation
Fig. 3) has to
PTT: when the PTT button is pushed
become RED
Battery type Alkaline or NiMH
Rev.02
G 470-566
H 542-640
I 566-686
L 678-798
K 520-640
