I
NTRODUCTION
Lite
"MTP40 is an extremely small and light pocket transmitter especially designed for
professional wireless microphone applications"
Very easy and quick to use thanks to OLED display, dedicated buttons and a joggle selector.
MTP40 Lite benefits also of the latest Wisycom RF technology along with an enhanced
robustness against noise and inter-modulation.
Fig. 1
Turn on display:
Push <select switch> and hold it.
Open MIC Body:
Push the side buttons and flip down the cover, to access
internal setup controls and batteries.
Switch to enable wireless transmission, it
❶
also indicates the battery status and
peak/mute operation (with PTT)
❷ In order to allow front visibility same colour
information on (1) is replicated with this LED
❸ Oled display for transmitter setup
❹ <ch>, <gain> and 3 positions <selector>
❺ Battery holder
❻ Cover (to open push side buttons)
1.
MTP40 Lite User Manual
1
Fig. 2
Turn on wireless:
Move the Wireless power switch in
"I" position: switch becomes green
(red indicate PTT/MUTE).
A green blinking gives you
indications on battery status.
Front LED color is the same
of power switch.
Rev.02
