- Page 1 EXPANDABLE MULTIFUNCTION CONTROL PANEL KYO 320 INSTALLATION MANUAL Vol.2 ® ISO 9001 ISO 9001 OHSAS 18001 OHSAS 18001 ISO 14001 ISO 14001 9105.BNT1 IT-52587 9191.BNT2 IT-52588 9192.BSEC IT - 60983...
- Page 2 The control keypads of KYO320 control panel are the CLASSIKA and PREMIUM LCD keypads. All previous Bentel LCD keypads (Alison-S, Alison-DVP, Mia-S, Mia-D) continue to be supported by the KYO320 Control panel. For a correct functionality of PREMIUM and CLASSIKA LCD keypad, the KYO 320 control panel must have a firmware rev. 2.06 or higher.
-
Page 3: Table Of Contents
TABLE of CONTENTS Dialler KEYPAD OPERATIONS Dig. comunicat. Introduction Answering Machine Using the keypad Voice messages Accessing the Installer menu Exiting the Installer menu Teleservice Num. teleservice Event logger Teleserv. param. Zone status Teleserv. option Zone test Init. teleservice Output test Maintenance call Clear call queue Central Station call... - Page 4 PREMIUM KEYPAD CLASSIKA KEYPAD PROXI READER Figura 1 Control Panel keypads: a) PREMIUM LCD; b) CLASSIKA LCD. KYO320...
-
Page 5: Keypad Operations
KEYPAD OPERATIONS Introduction Using the keypad You can operate your system from PREMIUM LCD and Read the following section carefully, to get an overall CLASSIKA LCD keypads, using the following options: view of how to use the Function keys. Event logger: this option will allow you to view the Event Logger. -
Page 6: Accessing The Installer Menu
In order to allow you to program the 32 Partitions of the When the system starts, on the display keypad is possi- KYO 320, from the keypad, this programming section ble to select the programming languages: has been divided into 4 Partition groups: 1st group —... -
Page 7: Exiting The Installer Menu
This command will allow you to view and print the tion if the Print Logger option is enabled (refer to events in the Event Logger. The KYO 320 Event logger “Print Logger” under “Configuration” in the can store up to 10,000 events. Events are stored in “PROGRAM PANEL”... -
Page 8: Zone Status
Staircase Window This function is provided by the optional K3-PRT2 STBY UNBYPASSED Printer Interface. The Event logger 4. Press ENTER again to view the Zone Resistance (in The Event logger is set up as follows: ohm, see the example below). Ø... -
Page 9: Output Test
Output test 44 seconds — for average sound quality. The recorded messages can be associated with the Control panel This option will allow you to test the system Outputs. Inputs for Telephone access, or sent to preset telepho- From the Installer menu: ne numbers (Dialler function), or used as Answer mes- sages (Answering machine function). -
Page 10: Installer Pin
Seconds fault, therefore, it can be used to change the PINs of all RemainingSec.150 the other Installer Codes, and also its own (0200 at de- fault). Installer Codes 196, 197, 198 and 199 have Son status, therefore, can change their own PINs only (re- The second line of display shows the remaining time to spectively 0196, 0197, 0198, 0199 at default). -
Page 11: User Codes
You cannot assign default PINs (refer to Table 10 Ø For full details on User Code programming, refer to on page 38). “Code Type” under “Control Panel Programming”. To program the User code parameters, carefully work If you attempt to assign a default PIN, the display will through the following steps. -
Page 12: Digital Keys
ID number is lower than 131 (131 not in- The top line of the display will show the ID number of the cluded) for KYO 320, it will become the sole Father first Reader in the configuration, while the bottom line Code of itself. -
Page 13: Program Panel
Program Panel 6. Use A or B to continue enrolling. Acceptance will be confirmed by the following message: The Control panel parameters can be programmed via ENROL WIRELESS keypad, refer to the “PROGRAM PANEL” section for Enrol details and instructions. When all the wireless detectors have been enrolled, Enroll wireless press ESC to go back to step 3 then, if you want to enrol... -
Page 14: Activating Wireless Detectors
Under certain circumstances, the Control panel is Wireless detectors should not be located in places that unable to detect changes, therefore, will not update give “bad” test results. the system Keypads. For example, if you ‘swap’ the If several devices produce “Bad” results, it may be description of two objects, the Control panel will be due to the Receiver, in which case, move the Rece- unable to detect the changeover and therefore will... -
Page 15: Release
Release If the keypad display is operating properly, it will show the letters A to P on the top and bottom line. If the LEDs I, a, G and M are operating properly, they will blink The Release option will allow you to view of the Control panel firmware release. - Page 16 KYO320...
-
Page 17: Program Panel
PROGRAM PANEL Configuration The Program Panel option will allow you to program all the parameters which determine system operation. Refer to “PROGRAMMING” in the INSTALLATION MANUAL The Configuration section is divided into different pro- for the description of the following parameters: gramming sections: Keypads, Readers, Input expan- ders, Output expanders, Power stations, Vector-RX Configuration:... -
Page 18: Led Keypads
If you enable the Part. Fast View option, memory of To unenrol a Keypad (delete from the Configuration), Partition Alarm and Tamper events will be signalled press OFF. by blinking on the respective character will blink. LED keypad n.001 Tamp./Al.Beep - Partition XXXXXXXX 6. -
Page 19: Input Expanders
Ev. on red LED n Input Expanders Event n. ---- From the Configuration menu, using A or B, select the Input Expanders option. To associate an event with the Red LED (enter the Configuration Event ID number (refer to the EVENT column in the Input Expanders “Events-Actions”... -
Page 20: Powerstation 001
Configuration To unenrol an Output Expander (delete from the Confi- Vector-RX module guration), press OFF. 5. Press ESC to go back to the Configuration menu. 1. Press ENTER: Vector-RX module n Power Station Not present This Control panel is unable to support Power stations. The following instructions are for upgraded models only. -
Page 21: Log Printer
Zones n Log Printer Wired zones From the Configuration menu, using A or B, select Log Printer. Configuration Using A or B, select Wired Zones or Wireless Zones. Log Printer Zones Wireless zones 1. Press ENTER: Wired Zones Options Print Logger From step 2 press ENTER. -
Page 22: Programming Alarm Zones
n Programming Alarm zones 9. press ENTER. Work carefully through the following steps. Cycles Zone Type Repetitive Instant 7c. Enter the required number of cycles, or enter all ze- 7a. Using A or B, select the Zone type (Instant, Entry ros to set Repetitive, then press ENTER and go to step delay, Entry path, Exit delay, Last exit, 24 hours, Fire or Duress). - Page 23 For Alarm zones — the Partition parameter determines 15. Using A or B, select the required Threshold: Low, the partitions the zone belongs to, and thus its operating Mid, High, enter the value (e.g. For 5 % enter 05), then times, codes and keys.
-
Page 24: And-Zone Groups
Timeout spectively, to enable or disable the respective attribute. Disabled The display will show the attribute status: “û” means Active, “-” NOT active. 14b.Enter the Inactivity Time (refer to “Inactivity”). 7b. Press ENTER. Using 0, select Disabled to disable Inactivity supervi- Cycles sion. -
Page 25: Outputs
Press ENTER: press ENTER. Oscillation None Only Outputs 1, 2 and 3 of KYO 320 can be pro- grammed as Superv.norm.clo. 12. Using A or B, select the Half Cycle of the oscilla- Follow tion. The Output will activate for the programmed time,... -
Page 26: Partition
Cicles Auto arm timeout Number Min. 13. Using A or B, set the number of Cycles for the Out- 8. Enter the time (in steps of 1 minute) of the Auto-arm put concerned. The Cycles can be set for the Monosta- timeout signal. -
Page 27: Keys/Card
Armed Mess.n --- 6. Using ON or OFF, respectively, enable or disable the None digital key concerned, then using A or B, select the Pa- trol attribute. Digital Key 15. Using A or B , select the Voice message (or None), Patrol assigned to Partition Armed status, then press ENTER: Disar.mess n.---... -
Page 28: Code Types
WLS Key NOTE: If, at step 3 (User type), you select a User Wireless Key 001 type (codes 1 through 16) go to “User Code Types”. If you select an Installer type (codes 17, 18 and 19) go to “Installer Code Types”. 5a. -
Page 29: Installer Code Types
Tamper wireless device des”). Press ON or OFF, respectively, to enable or disa- ble the function concerned (“û” means enabled, and “-” Tabella 3 KYO 320 Panel events means disabled). Press ENTER to go to the next Option section. EVENTI... - Page 30 Tabella 4 Generic events (Continued) for KYO320 Warning mains failure on Power 0984 station 0985 EVENT Warning low battery on Power station 2643 Warning power trouble on Power Test 0986 station 2643+n Reset on partition no. Battery not connected on Power 0987 2676 Reset on panel...
-
Page 31: Events - Actions
event ends (enter all zeros for NO action), then using A EVENTO or B, select Dialler On. 3415 Memo message present Event 0001 3416 K-NET module missing Dialler On 3417 Lan Link missing 3418 IP receiver missing 7. Enter the ID number of the Dialler action which the Control panel must perform when the selected event Tabella 7 Special events for KYO320. -
Page 32: Telephone
Telephone lephone number, press and hold 1 until the keypad emits a beep. The Telephone option will allow you to setup the Con- If you wish to include pound (#) or star (*) in the te- trol panel Phonebook, the telephone line parameters lephone numbers, you must program the telepho- and the Answering machine. - Page 33 sage. The bottom line of the display will show the Voice Dialler numbers message label (Description). Press ENTER or ESC, re- Dialler numbers spectively, to go to the next or previous Dialler message Number (message 1, 2, 3, 4 or 5). Using A or B, select the Voice message for the selected Dialler message.
-
Page 34: Dig. Comunicat
Protocol 10d. Using A or B, select the Dial, Timeout or Voice ADEMCO SLOW on line option, then press ENTER. Refer to the respec- tive paragraph for instructions. 7g. Using A or B, select the Protocol supported by the Timeout Central Station the Digital Communicator call will be sent to, then press ENTER. -
Page 35: Answering Machine
Event code Voice messages Code 1.Using A or B, select the Vocal messages option. PROGRAMMING 9h. Enter the Event code (refer to “Code”) of the action Vocal messages being programmed, (This is not valid for Contact ID, SIA and SIA over K-NET protocols) then press ENTER to go back to step 5h. -
Page 36: Num. Teleservice
nance call or Vigilance call, then press ENTER and 5c. Press ON or OFF, respectively, to enable or disable refer to the respective paragraph. the Callback option. If this option is enabled, the Con- trol panel will call the programmed Teleservice num- n Num. -
Page 37: Central Station Call
Option section 2 5h. Enter the keypad message for the Installer Mainte- Block ist.code - nance Request memo (refer to “Entering a text” under “Using the Keypad”), then press E to go back to step 3. 7. Using A or B, select the required option (see Table n Central Station call 9), then press ON or OFF, respectively, to enable or di- Cent.Stat.Date... -
Page 38: Default Pin
3. Enter the Overtime length (in minutes), then press Disab.False Key Disable false key event ENTER to go to the next parameter. Valid entries: 0 Disable arming on wireless through 60 minutes. NoArmReceivLost receiver lost Max overtime n. Disable arming on wireless zone (Max 009) NoArm ZoneTroub fault... -
Page 39: Appendix
APPENDIX n Installation K3/VOX2 Voice Board Work carefully through the following steps (see Figure 2 Disconnect the Mains and battery power before and Figure 2 in the Installation Manual Vol.1). starting the installation procedure. 1. Insert the Speaker into one part of the plastic hol- The K3/VOX2 Voice board records and plays Voice der. -
Page 40: Manual Selection
Ø All the Outputs of the M-IN/OUT Expander, program- or similar. The installation instructions can be found in the MINI-BOX package. med as Expander with 6 Outputs, as such must be Reserved Outputs (manual), Bistable, Normally The Microphone and Loudspeaker should be hou- Open;... -
Page 41: Manual And Auto-Select Mode
n Manual and Auto-select mode Software Outputs 7, 8, 9 and 10 (available for this ap- plication) must be: Monostable and Normally open Manual and Auto-select Listen-in can be integrated. (DO NOT program these Outputs as Reserved). This will allow the User to select (manually) specific lo- The ON Time of the Output determines how long the cations during standby status. -
Page 42: K3/Prt2 Printer Interface
n Connecting the Printer K3/PRT2 Printer Interface If you prefer to chase the lead, use a plug-free cable (re- Disconnect the Mains and battery power before fer to Table 11 for the wiring specifications and see also starting the installation procedure. Figure 6). -
Page 43: Wireless Receivers
Wireless Receivers DESCRIPTION 118 Spring catch slots (2) The VRX32-433 and VRX32-868 Receiver (accessory 119 Anchor screw locations (3 x ø 4.6 mm) item) will allow your system to manage up to 32 Wire- 120 Antennas (2) less detectors (PIRs, Magnetic Contacts, Smoke detec- 121 Microprocessors (2) tors), and up to 16 Wireless keys (KeyFobs). -
Page 44: Connecting The Receiver
6. Place the backplate in the proposed placement, pull the wires through the wire entry 125, then secure the backplate to the wall (use anchor screws). 130 131 129 7. Complete the connections on the terminal board 127 (refer to “Connecting the Receiver”). +V M OC PC-LINK 8. -
Page 45: K-Net Module
n Mounting the K-NET Module K-NET MODULE Installing the K-NET Module (Refer to K-NET manual), The K-NET Module should be installed in the control will allow you to connect several Control panels to the unit base, as illustrated in Figure 11 and in accordance LAN and control them from a remote location . -
Page 46: Viewing The Ip Address
8. Program the K-NET Module as described in the 5. Reset the power supply to the Control Panel (see "Programming" section of the K-NET manual. “Connecting Power Supply” “INSTALLATION” chapter in the Installation Ma- n Viewing the IP Address nual, Vol.1). If the DHCP is configured, the current IP address of the KNET circuit board may be checked in 2 ways: Jumper 21 (M) must be disconnected for at le-... - Page 47 EVENT CONTACT ID CL. CODE GROUP ZONE TYPE Burglar alarm on partition part. no. BA/BR part. no. Generic alarm on partition part. no. BA/BR part. no. Tamper alarm on partition part. no. TA/TR part. no. Generic+Tamper alarm on partition part. no. TA/TR part.
- Page 48 EVENT CONTACT ID CL. CODE GROUP ZONE TYPE Warning low battery on Power station YT/YR 0000 Warning power trouble on Power station YM/YR 0000 Battery not connected on Power station YP/YQ 0000 Battery charger trouble on Power station YP/YQ 0000 Switching not connected on Power station YP/YQ 0000...
- Page 49 0 and 1 of the binary digit which transmits the following data: DbManager (in Bentel security Suite) is an application developed to copy safely customer’s data from a source Ø User Code (4 digits — 0 through 9) to a destination.
-
Page 50: Dbmanager
Origin Select the disk and folder which contains the cation will enable the Create option automatically. customer accounts concerned. The Bentel security Suite application will save cu- Panel types Check in this box panel types involved in stomer account data to the \DATA installation fol- the data transfer. -
Page 51: Copying Customer Accounts
1. Select Export data from the File menu. Access Levels menu provides the possibility to ma- nage users data for all Bentel Security Suite softwares. 2. Select the disk and folder of the customer accounts concerned from the Origin box. - Page 52 ® BENTEL SECURITY s.r.l. Via Gabbiano, 22 Zona Ind. S. Scolastica 64013 Corropoli (TE) -ITALY Tel.: +39 0861 839060 Fax: +39 0861 839065 e-mail: infobentelsecurity@tycoint.com http:www.bentelsecurity.com ISTPTBLEKYO320 5.0 171013 v10...
