Printer Mgmt; Printer Mgmt Submenus - Printronix SL5000 User Manual

PRINTER MGMT

PRINTER
MGMT
(from page 105)
PNE Port Mgmt
Protocol
Ethernet* UCP*
Disable PXML
Serial

PRINTER MGMT Submenus

PNE Port
This menu selects which port the printer expects PNE to connect to, via
Ethernet or Serial. The factory default is Ethernet only if the NIC is installed.
Mgmt Protocol
Since PXML and UCP management protocols share the same Ethernet Port,
only one can be active at a time. This menu selects the active Management
Protocol Interface, either PXML or UCP. The factory default is UCP.
PNE Port Number
This menu selects the port number the printer expects PNE to connect
through. The factory default is 3001 and the range is from 1023 to 65535.
PNE Port Timeout
If PNE has not communicated to the printer within a timeout period, the PNE
session closes. The factory default is 100 seconds. The range is from 1 to 255
seconds.
Status Port Numb
This menu selects the port number the printer sends the emulation status.
The factory default is 3006 and the range is from 1023 to 65535.
Mgmt Port Number
This menu selects the port number the printer expects the PXML or UCP to
connect through. The factory default is 3007 and the range is from 1023 to
65535.
PNE Port PNE Port
Number Timeout
3001* 100 Seconds*
1023 - 65535 1 - 255 Seconds
PRINTER MGMT Submenus
Notes:
* = Factory Default
Status Port
Mgmt Port
Numb
Number
3006*
3007*
1023 - 65535
1023 - 65535
277
