Num Auto Labels
The desired number of labels to be printed vertically adjacent on the form.
The value is selectable with a range of 2 through 40 (T5X04), 2 through 21
(T5X06) and 2 through 17 (T5X08).
The factory default is 2.
Slew Speed
The speed at which the printer moves media without actually printing on it.
•
Automatic. Always the same as the print speed (see "Print Speed" on
page 107).
•
Manual. Allows you to set the slew speed. The maximum speed depends
on your printer model (see Table 18 on page 345).
The slew speed can be set to Automatic, Manual, 6 ips, or 1 to 10 ips.
The factory default is Automatic.
Print Direction
This option determines the basic print image orientation.
NOTE: Print Direction will not change the orientation of any print test patterns
in the DIAGNOSTIC menu.
Print Direction has two options:
•
Head First
•
Foot First
For example, with Portrait orientation, when you select Head First, the top-of-
form will come out of the printer first. Conversely, when you select Foot First,
the bottom-of-form will come out first.
FEED
Head First
MEDIA CONTROL Submenus
A
Foot First
