Chapter
2
Loading Media And Ribbon
Ribbon
Printhead
Media
4. Thread the end of the ribbon under the rear ribbon guide roller, then
between the platen and the printhead.
You can also refer to the arrows on the printer frame or to the upper-right
corner of the label inside the media cover for ribbon loading instructions.
52
Rear Ribbon
Guide Roller
