Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
2.6. Settings at the ETS-Software
Selection at the product database:
Manufacturer: MDT Technologies
Product family: Control
Product type: Any
Medium Type: Twisted Pair (TP)
Product name: SCN-RT1GW.01
Order number: SCN-RT1GW.01
2.7. Starting up
After wiring the allocation of the physical address and the parameterization of every channel follow:
(1) Connect the interface with the bus, e.g. MDT USB interface
(2) set bus power up
(3) Press the programming button at the device(red programming LED lights)
(4) Loading of the physical address out of the ETS-Software by using the interface(red LED goes
out, as well this process was completed successful)
(5) Loading of the application, with requested parameterization
(6) If the device is enabled you can test the requested functions(also possible by using the ETS-
Software)
