4
Heat alarm
5
External sensor
6
Setpoint comfort
7
Manual setpoint value
offset
8
Control value heating
MDT technologies GmbH • 51766 Engelskirchen • Papiermühle 1 • Tel.: +49-2263-880 • Fax: +49-2263-4588 • knx@mdt.de • www.mdt.de
11
Technical Manual Glass Room Temp. Contr. SCN-RT1Gx.01
Send alarm
DPT 1.001
Read external sensor
DPT 9.001
Set setpoint
DPT 9.001
Reduction/Increase
DPT 9.002
Send control value
DPT 1.001/
DPT 5.001
send
Controller sends
state
receive
Controller receives
external
temperature
receive
Controller receives
new absolute
setpoint
receive
Controller receives
new setpoint
offset
send
Controller sends
manipulated value
Visu, Display,
Communication object is
Diagnostic,
shown when alarms are active
Additio al stage,...
Input for external
Communication object is
temperature
shown when sensor is set to at
least 10% external sensor
Visu, Opereating
Object is permanent shown
keys, Control unit
when the controller is active. A
new setpoint can be set via this
object.
Visu, Display,
Object is shown when the
Operating keys,
setpoint offset via 2 Byte
Control unit
object is active. The setpoint is
shifted according to the
current setpoint.
Heating actuator,
Object is shown when the
actuators
controller is set to heating. The
DPT depends to the controller
type (two-level & PWM –
DPT1.001, PI-DPT5.001).
