Elevator Pushrod; Rudder Pushrod - THE WORLD MODELS 1/3 Clipped Wing Cub Instruction Manual

Fuel Tank
11

Elevator Pushrod

12
PM4x40mm Screw
2
M4 NYLON INSERT LOCK NUT
2
Heavy Duty Horn Bracket
M2 Nut
Heavy Duty
Clevis
PM2x8mm
PM4x40mm
Elevator Pushrod

Rudder Pushrod

13
PM4x60mm Screw
1
M4 NYLON INSERT LOCK NUT
1
M4 Nylon Insert
PM4x60mm
Lock Nut
Heavy Duty Horn
Bracket
1mm
M4 Nylon Insert
Lock Nut
PA1.7x8mm
1mm
PA1.7x8mm
Heavy Duty
Clevis
M2 Nut
Pushrod
PM2x8mm
Fuel Tank
1500cc
UP
Bottom View
Bottom View
P.7
Install Wood 12x12x197mm
(For Fuel Tank Position Fixing)
Fuel Tank
Bottom View
Completed
