THE WORLD MODELS 1/3 Clipped Wing Cub Instruction Manual page 9

Flying Wire
14
3mm Set Screw
4
d3.6mm Collar
4
PM 3x18mm Screw
3
M3 NYLON INSERT LOCK NUT
3
3mm
M3
M3x3mm
Set SCREW
Windows
15
Window A
Securely glue the windows to the fuselage.
16
Servo Set
3x3mm Set Screw
1
Linkage Connector
1
M2 Nut
1
2mm Washer
2
3mm
d5xD6.4x10mm
Completed
Throttle Pushwire
1.5mm
Please refer to the attached sheet for linkage connector installation.
Copper Tube
M3
Press down the center
1/3 portion
Window B
3mm
2mm
2mm
M2 Nut
P.8
COMPLETED
Throttle Servo.
