Christie D4K3560 Setup Manual

Hide thumbs Also See for D4K3560:
Table of Contents

Advertisement

Quick Links

Download this manual
D4K3560
S e t u p G u i d e
020-101161-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D4K3560 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Christie D4K3560

Summary of Contents for Christie D4K3560

  • Page 1 D4K3560 S e t u p G u i d e 020-101161-05...
  • Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.
  • Page 3 CAN ICES-3 (A) / NMB-3 (A) 이 기기는 업무용 (A 급 ) 으로 전자파적합등록을 한 기기이오니 판매자 또는 사용자는 이점을 주의하시기 바라며 , 가정 외의 지역에서 사용하는 것을 목적으로 합니다 . Environmental The product is designed and manufactured with high-quality materials and components that can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from regular waste.

  • Page 4: Table Of Contents

    Connect a video source using DisplayPort ......29 D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)
  • Page 5 D4K3560 signal connectivity ........

  • Page 6: Introduction

    Safety and warning guidelines This projector must be operated in an environment that meets the operating range specification. Use only the attachments and/or accessories recommended by Christie. Use of others may result in the risk of fire, shock, or personal injury.

  • Page 7: Installation Safety And Warning Guidelines

    • Verify that the projector is using a line cord, socket, and power plug that meets the appropriate local rating standards. Use only an AC power cord recommended by Christie. Do not attempt operation if the AC supply and cord are not within the specified voltage and power range.

  • Page 8: Lamp Precautions

    This equipment is included in included in the Christie Protective Clothing Safety kit P/N: 598900-095. Christie’s protective clothing recommendations are subject to change. Any local or federal specifications take precedence over Christie recommendations. D4K3560 Setup Guide...

  • Page 9: Product Safety Labels

    Indicates exposure to bright light. To avoid personal injury, never look directly at the light source. Indicates the presence of an explosion hazard. To avoid personal injury, always disconnect all power sources and wear Christie approved protective clothing. D4K3560 Setup Guide...
  • Page 10 This label warns of a cross-connection hazard when installing multiple projectors at once. A fire hazard exists if a lamp power supply interlock cable is connected to a different projector than its lamp power cables. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 11: Installation And Setup

    Three-phase, 26A 380-415VAC + Neutral + Earth (regions outside North America and Japan) • This product can be connected to an IT power distribution system. Tools required for installation • 12” screwdrivers: Phillips #2 (magnetic) and flat D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 12: Projector Components

    Installation and Setup • 19 mm and 7/8” wrenches • Assorted Allen keys (metric) • Christie approved protective safety clothing if working with the lamp • Lens cleaning tissue and solution Projector components LAMP SIDE LENS SIDE Description Touch panel controller A touch-sensitive screen used to control and monitor operation.
  • Page 13 Projection lens A variety of projection lenses can be used with the projector. For a list of available lenses, see the D4K3560 User Manual (P/N: 020-101075-XX). Air filter cover and air Filters the intake air before it circulates through the front compartment to cool filter the main electronics.

  • Page 14: Lamp Power Supply Components

    15A or more. Power phase indicator Indicates the power on each of the three phases. lights LPS power inlet Supplies power to the LPS. This connection must be professionally wired, according to local regulations. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 15: Position The Projector

    3. Insert the lamp power supply (LPS) support into the rack stand and align the pins with the holes. 4. Lift the LPS into the frame. 5. Remove the bottom 10 panels from the back of the rack stand. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)
  • Page 16 10. When installing other components in the rack stand allow at least two inches of clearance above the LPS handles for ease of servicing. 11. Wire all components within the rack stand and replace the side panel. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 17: Connect The Lamp Power Supply

    Connect one end of the RS232 cable to the lower port on the LPS labeled RS232. b. Connect one end of the Interlock cable to the upper port on the LPS labeled Interlock. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)
  • Page 18 Configuring ballast settings for 200 VAC operation using a 200 VAC supply, see on page 20, or to the right when using a 400 VAC supply see Configuring ballast settings for 400 VAC operation on page 20. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)
  • Page 19 Internal input line voltage switch setting must match AC available on site. 6. Connect one end of the line cord into the LPS power connector labeled Projector ONLY. If using the longer DC cable kits, the projector head must be powered separately using Christie recommended line cord provided for your region.

  • Page 20: Configuring Ballast Settings For 200 Vac Operation

    Ensure the wire insulation is not crimped under the screw. 5. Slide the selector switch to the 200V location. 6. Re-attach the front panel. Configuring ballast settings for 400 VAC operation 1. Unplug the LPS from power. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)
  • Page 21 4. Tighten the screw to secure the harness in place. Ensure the wire insulation is not crimped under the screw. 5. Slide the selector switch to the 400V location. 6. Re-attach the front panel. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 22: Adjust The Projector Tilt And Level

    2. Remove the feet by loosening the lock nut and rotating the each foot out of the projector. 3. Add the extension rods to the standard feet. 4. Thread the extended feet into the projector’s baseplate. 5. Adjust the feet until the required tilt is achieved. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 23: Install The Touch Panel Controller

    Notice. Failure to comply with the following may result in property damage. *600 CFM is required in projection rooms with an ambient temperature above 25°C or located at an elevation greater than 3000 feet above sea level. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 24: Remove The Projector Shroud

    To prevent the projector from overheating or becoming unsafe, an alarm sounds if the duct is obstructed or a fan fails. Christie recommends regularly verifying that the exhaust is unobstructed and functioning correctly.

  • Page 25: Set Up The Lens

    Always install the lens with UP label in the top position to achieve consistent boresight alignment each time the lens is replaced. 5. Secure the lens with the lens locking lever (down position). 6. Calibrate the lens motors. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 26: Setup The Lamp

    For remote applications, the TPC can be dismounted from the projector and used with the optional cable to allow projector control from a maximum distance of 100 ft (30 m). D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 27: Connect Devices

    The following table shows the video quadrant mappings for the 3GIC, TDPIC, and THIC Four-Port input configurations: input Quadrants Columns Four-Port configuration—Two cards (1) Slot 1 1-In Top left 1 (left most) Slot 1 2-In Bottom left D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 28: Four-Port: Ddic Card

    The following table shows the video quadrant mappings for the DDIC Two-Port input configuration: input Columns Two-Port Configuration—Two cards (1) Slot 1 1-Dual Link DVI-I 1 (left most) Slot 2 1-Dual Link DVI-I D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 29: Connect A Video Source Using Displayport

    One-Port Enables connection of one SDI cable to the 1-IN input of a 3GIC card One 3GIC card (in any slot). In this configuration the SDI input supplies the entire video raster. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 30: Connect A Video Source Using Hdmi

    4K image. One-Port Enables connection of one DVI cable to the DVI input of a DDIC card One DDIC card (in any slot). In this configuration, the DVI input supplies the entire video raster. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 31: Select A Video Source

    Notice. Failure to comply with the following may result in property damage. The RS232 port located on the MCPU faceplate uses Christie-proprietary protocol and is intended for Christie accessories or automation controllers only. For more information on the serial commands,...
  • Page 32 2. Set the network information for the projector: • To obtain information automatically from the network, tap Automatic. To manually enter the network information, tap Manual and enter the IP Address, • Subnet Mask and Gateway (optional). 3. Click Ok. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 33: D4K3560 Signal Connectivity

    Connect Devices D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 34: Operation

    1. Set the all the breaker switches on the lamp power supply to their on positions. 2. Set the breaker switch on the projector baseplate to the on position. 3. When the projector reaches standby, on the touch panel controller, tap Home > Power. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)

  • Page 35: Led Expected Behavior On Power Up

    1. On the touch panel controller, tap the Home tab. 2. Tap Power. When powering off in preparation for inspection or maintenance, always disconnect from AC, set the projector breaker and lamp power supply breakers to the off positions. D4K3560 Setup Guide 020-101161-05 Rev. 1 (06-2015)
