  • Page 1 D4K2560 S e t u p G u i d e 020-101171-04...
  • Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.
  • Page 3 CAN ICES-3 (A) / NMB-3 (A) 이 기기는 업무용 (A 급 ) 으로 전자파적합등록을 한 기기이오니 판매자 또는 사용자는 이점을 주의하시기 바라며 , 가정 외의 지역에서 사용하는 것을 목적으로 합니다 . Environmental The product is designed and manufactured with high-quality materials and components that can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from regular waste.

  • Page 4: Table Of Contents

    Select a video source ..........25 D4K2560 Setup Guide...
  • Page 5 D4K2560 signal connectivity ........

  • Page 6: Introduction

    Safety and warning guidelines This projector must be operated in an environment that meets the operating range specification. Use only the attachments and/or accessories recommended by Christie. Use of others may result in the risk of fire, shock, or personal injury.

  • Page 7: Installation Safety And Warning Guidelines

    • Verify that the projector is using a line cord, socket, and power plug that meets the appropriate local rating standards. Use only an AC power cord recommended by Christie. Do not attempt operation if the AC supply and cord are not within the specified voltage and power range.

  • Page 8: Lamp Precautions

    This equipment is included in included in the Christie Protective Clothing Safety kit P/N: 598900-095. Christie’s protective clothing recommendations are subject to change. Any local or federal specifications take precedence over Christie recommendations. D4K2560 Setup Guide...

  • Page 9: Product Safety Labels

    Indicates exposure to bright light. To avoid personal injury, never look directly at the light source. Indicates the presence of an explosion hazard. To avoid personal injury, always disconnect all power sources and wear Christie approved protective clothing. Indicates the presence of a fire hazard. To avoid personal injury and property damage, always adhere to the instructions described in this manual.
  • Page 10 For more information, see Adjust the projector tilt and level in the Installation and Setup chapter D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 11: Installation And Setup

    12” screwdrivers: Phillips #2 (magnetic) and flat • 19mm and 7/8” wrenches • Assorted Allen keys (metric) • Christie approved protective safety clothing if working with the lamp • Lens cleaning tissue and solution D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 12: Projector Components

    Shroud (two-piece) Covers the motorized lens mount assembly. Projection lens A variety of lenses can be used with the D4K2560. For a list of available lenses, see the D4K2560 User Manual (P/N: 020-101076-XX). Air filter cover and air filter Filters the intake air before it circulates through the front compartment to cool the main electronics.

  • Page 13: Position The Projector

    2. If using an optional rack stand (P/N: 108-282101-02), assemble the rack stand using the instructions provided with the rack stand. Use the hold down clamp (P/N: 116-100101-01) when securing the projector to the rack stand. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 14: Connect To Ac Power

    2. Remove the four screws securing the knockout plate to the bottom right corner of the front bezel. Remove the knockout plate. The AC supply is routed to the terminal block through an appropriate strain relief mounted on this knockout plate. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)
  • Page 15 4. Reinstall the knockout plate and secure it with four screws. 5. Reinstall the bottom access panel over the terminal block and secure it with two screws. 6. If using a pluggable type-B cable, connect to the building’s AC power source. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 16: Adjust The Projector Tilt And Level

    2. Remove the feet by loosening the lock nut and rotating the each foot out of the projector. 3. Add the extension rods to the standard feet. 4. Thread the extended feet into the projector’s baseplate. 5. Adjust the feet until the required tilt is achieved. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 17: Install The Touch Panel Controller

    Notice. Failure to comply with the following may result in property damage. *600 CFM is required in projection rooms with an ambient temperature above 25°C or located at an elevation greater than 3000 feet above sea level. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 18: Remove The Projector Shroud

    To prevent the projector from overheating or becoming unsafe, an alarm sounds if the duct is obstructed or a fan fails. Christie recommends regularly verifying that the exhaust is unobstructed and functioning correctly.

  • Page 19: Set Up The Lens

    Always install the lens with UP label in the top position to achieve consistent boresight alignment each time the lens is replaced. 5. Secure the lens with the lens locking lever (down position). 6. Calibrate the lens motors. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 20: Setup The Lamp

    For remote applications, the TPC can be dismounted from the projector and used with the optional cable to allow projector control from a maximum distance of 100 ft (30 m). D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 21: Connect Devices

    The following table shows the video quadrant mappings for the 3GIC, TDPIC, and THIC Four-Port input configurations: Four-Port Input Configuration—Two Cards (1) Quadrants Columns Slot 1 1-In Top left 1 (left most) Slot 1 2-In Bottom left D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 22: Four-Port: Ddic Card

    1-In Two-Port Input Configuration—Two Cards (2) Columns Slot 3 1-In 1 (left most) Slot 4 1-In Two-Port: DDIC card Two-Port Input Configuration—Two Cards (1) Columns Slot 1 1-Dual Link DVI-I 1 (left most) D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 23: Connect A Video Source Using Displayport

    One-Port Enables connection of one SDI cable to the 1-IN input of a 3GIC card One 3GIC card (in any slot). In this configuration the SDI input supplies the entire video raster. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 24: Connect A Video Source Using Hdmi

    4K image. One-Port Enables connection of one DVI cable to the DVI input of a DDIC card One DDIC card (in any slot). In this configuration, the DVI input supplies the entire video raster. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 25: Select A Video Source

    Notice. Failure to comply with the following may result in property damage. The RS232 port located on the MCPU faceplate uses Christie-proprietary protocol and is intended for Christie accessories or automation controllers only. For more information on the serial commands,...

  • Page 26: Set Up The Ethernet

    2. Set the network information for the projector: • To obtain information automatically from the network, tap Automatic. • To manually enter the network information, tap Manual and enter the IP Address, Subnet Mask and Gateway (optional). 3. Click Ok. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 27: D4K2560 Signal Connectivity

    Connect Devices D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 28: Operation

    • Do not attempt to turn the projector on if the AC supply is not within the specified voltage range. 1. Set the breaker switch on the projector baseplate to the on position. 2. When the projector reaches standby, on the touch panel controller, tap Home > Power. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)

  • Page 29: Led Expected Behavior On Power Up

    1. On the touch panel controller, tap the Home tab. 2. Tap Power. When powering off in preparation for inspection or maintenance, always disconnect from AC and set the projector breaker to the off positions. D4K2560 Setup Guide 020-101171-04 Rev. 1 (01-2015)
