Seagull Models Mini Nemsis EP Assembly Manual page 11

4) Locate the plywood battery tray to the
fuselage.
5) Attach the speed control to the side of the
motor box using two-sided tape and tie wraps.
Connect the appropriate leads from the speed
control to the motor. Make sure the leads will
not interfere with the operation of the motor.
1800mAh-2100mAh.
Battery.
Speed control.
15A-30A.
COWLING.
1) Slide the fiberglass cowl over the motor
and line up the back edge of the cowl with the
marks you made on the fuselage then trim and
cut as shown.
www.seagullmodels.com
Battery.
Because of the size of the cowl, it may be nec-
essary to use a needle valve extension for the
high speed needle valve. Make this out of suf-
ficient length 1mm wire and install it into the
end of the needle valve. Secure the wire in
place by tightening the set screw in the side of
the needle valve.
cowl flush with the marks, align the front of
the cowl with the crankshaft of the engine. The
front of the cowl should be positioned so the
crankshaft is in nearly the middle of the cowl
opening. Use the spinner backplate as a guide.
Hold the cowl firmly in place using pieces of
masking tape.
Trim and cut.
2) While keeping the back edge of the
11
