Seagull Models Mini Nemsis EP Assembly Manual page 10

MINI NEMSIS EP
ELECTRIC POWER ASSEMBLY.
1) Locate the items neccessary to install the
electric power installation.
450-480.
15A-30A.
2) Attach the electric motor box to the firewall
suitable with the cross lines drawn on the electric
motor box and firewall. Using epoxy and balsa
stick to secure the motor box to the firewall.
Please see pictures below.
3) Attach the motor to the front of the electric
motor box using four 3mm blind nut, four
M3x15mm hex head bolts to secure the motor.
Please see picture shown.
10
Instruction Manual.
4mm.
M3 x 15mm.
Epoxy.
140mm.
Electric motor.
Balsa.
Epoxy.
