IN1404 on-screen display
menu system
Video
Brightness
Contrast
3
RGB Gain
2
Color Saturation
2
Hue
2
Sharpness
2
Gamma
2
Noise Filter
2
Comp/Trap
Reset Video
3
RGB Gain
Red
Green
Blue
2
Comb/Trap
Comb Filter On
Trap Filter On
Reset Video
Yes
No
Audio
Bass
Treble
Balance
Reset Audio
Reset Audio
Yes
No
Input #
Composite
S-video
4
Component Interlaced
Component
4
RGBS
4
RGsB
4
RGBHVS Passive
4
RGsB Passive
Advanced Features
(under Input menu)
Active Area
Active Pixels
Active Lines
Blanking
H-Blanking
V-Blanking
3
Scan Type
Interlaced
Swap Fields
Invert Sync
Input Mode
Auto Detect
Lockout Changes
User Defined
Redetect Now
IN1404 User's Manual
Main Menu
Video
Audio
Input
Output
Advanced
Input
Signal Format
Aspect Ratio
Auto Switching
Input Labels
Horiz. Tracking
Phase
Advanced
Reset Input
Signal Format
Input 1
Input 2
Input 3
Input 4
Aspect Ratio
Standard
Anamorphic
Wide Screen
Wider Screen
Tomarama
Auto Switching
On / Off
Input Labels
On / Off
Momentary
Reset label
Horizontal
3
Tracking
Very Fast
Fast
Normal
Slow
Advanced
Active Area
Blanking
Total Pixels3
Scan Type
Input Mode
Reset Input
Yes / No
Output
Resolution
Refresh Rate
Size
Position
Sync Format
Blue Screen
Reset Output
Resolution
640 x 480
800 x 600
852 x 480
1024 x 768
1152 x 864
1280 x 720
1280 x 1024
1365 x 768
1365 x 1024
5
Refresh Rate
56 / 60 / 65 Hz
72 / 75 Hz
85 / 96 Hz
100 Hz
120 Hz
Size
H-Size
V-Size
Position
H-Position
V-Position
Sync Format
RGBHV--
RGBHV++
RGBS A
RGBS B
RGsB A
RGsB B
Blue Screen
On/Off
Reset Output
Yes/No
Advanced
Factory Reset
User Memory
Baud Rate
Delimiters
Reset RS-232
System Info
Factory Reset
Yes
No
User Memory
Save
Recall
Reset
Baud Rate
1200
2400
4800
9600
19200
38400
57600
Delimiters
Parenthesis
Brackets
Slashes
Less & Greater
Signs !#
Reset RS-232
Yes
No
System Info
Input #
Signal Format
Input Horiz.
Input Vert.
Output Size
Output Horiz.
Output Vert.
Sync Format
Version
9
