Seagull Models ERCOUPE Assembly Manual page 10

ERCOUPE
Crimp.
Cableend.
10
Instruction Manual.
1
M3
2
COWLING.
1)Slide the fiberglass cowl over the engine
and line up the back edge of the cowl with the
marks you made on the fuselage then trim and
cut as shown.
Because of the size of the cowl, it may be nec-
essary to use a needle valve extension for the
high speed needle valve. Make this out of suf-
ficient length 1.5mm wire and install it into the
end of the needle valve. Secure the wire in
place by tightening the set screw in the side of
the needle valve.
Trim and cut.
