*Also used for keyboard Pop-up feature (HID Mode only)
Blue/Green/Red
LED
Trigger button
Power button*
DC-in connector
Battery door
Twist-lock
(horizontal/unlocked)
Disc for magnet on
stand charger
Twist-lock
(vertical/locked)
Lanyard
PRODUCT INFORMATION
PRODUCT INFORMATION
Product label
Scanner head
Pins for
charging
cradle
3
