QUICK START GUIDE
Bluetooth
Series 7

1D Laser Models — CHS 7Mi, 7Pi
This document pertains to the following CHS v3 models:
 7Mi
SKU# CX2872-1411 (P/N 8550-00063)
 7Pi
SKU# CX2874-1413 (P/N 8550-00064)
The part number (P/N) is labeled inside the battery compartment.
© 2010-2013 Socket Mobile, Inc. All rights reserved. Socket, the Socket logo, SocketScan, Socket Bluetooth Cordless Hand Scanner, and Business
Mobility Now! are registered trademarks or trademarks of Socket Mobile, Inc. The Bluetooth word mark and logo are registered trademarks of
the Bluetooth SIG, Inc. USA, and any use by Socket Mobile, Inc. is under license. All other trademarks and trade names contained herein may be
those of their respective owners.
®
 Cordless Hand Scanner (CHS)
LED
Trigger button
Power button
(also for iOS Keyboard Pop-up)
PACKAGE CONTENTS
 Socket Bluetooth Cordless Hand Scanner (CHS)
 Lanyard / belt clip with retractable tether
 Rechargeable batteries (2)
 AC adapter with international plugs
 USB to DC plug cable
 CD with software and documentation
HELPFUL RESOURCES

Software and Documentation Downloads:
Download the latest software and manuals from:
http://www.socketmobile.com/support/downloads/data-collection/series7/ss10/
 User's Guide: Full installation and usage instructions available online.
 Command Barcodes Sheet: Scan to configure the CHS. Many are at the end
of this Quick Start Guide. For a full set, download Command Barcodes Sheet.
Product Registration:
Need technical support? Want to opt-in for special offers? Register your
product online:
http://support.socketmobile.com/
Alternatively, if you install SocketScan 10 software for Android / Windows /
BlackBerry OS or Scanner Settings for iOS, you can use it to register the CHS.
Technical Support:
 Online Knowledge Base:
http://support.socketmobile.com/EU_S1a.asp
 Online Requests: Register to submit an inquiry.
 Phone: +1-510-933-3020
USA/Canada +1-800-279-1390
Software Development Kit:
SocketScan 10 SDK for Apple iOS, Android, BlackBerry and Windows is
available to members of the Socket Mobile Developer Program ($19.95/year).
Learn more at:
http://developer.socketmobile.com/
Thank you for choosing Socket Mobile!
