Safety instruction

• Read this safety instruction and the manual first.
• Follow all instructions and information.
• Do not loose this manual.
• Do not use this apparatus under the rain or near
the water.
• Do not install the apparatus near heaters or in hot
environments, do not use outside the operating
temperature range.
• Do not open the apparatus, only qualified service
technician are enabled to operate on it. The appa-
ratus needs servicing when it is not properly work-
ing or is damaged by liquids, moisture or other
objects are fallen in the apparatus.
• Use only accessories or replacement parts autho-
rized or specified by the manufacturer.
• Clean the apparatus only with dry cloths, do not
use liquids.
• Report the serial number and the purchasing date
in front of the manual. It is needed to have proper
replacement parts or accessories from the manu-
facturer.
• When replacement parts are needed, use only
replacement parts authorized from the manufac-
turer. Substitution with not authorized parts could
result in electric shock, hazards or fire.
Keep attention on all the labels with warnings
»
or hazards on the apparatus.
WARNING: The apparatus is intended for
professional use; anyway the manufacturer alerts
the user that the headphone output power of the ap-
paratus could exceed the level of 85 dB(A) of sound
pressure level and this could be dangerous for the
hearings. Do not use the headphone with high power
level or for long time. Reduce the power or suspend
the hearing in case of any kind of hearing problem.
WARNING: when operating thru battery pack
always replace ALL BATTERIES.
DO NOT operate the device with some new and
some old batteries.
When MCR42 is setup to "automatically turn on", DO
CHANGE ALL OF USED BATTERIES after automatic
low batteries shutdown.
Pag. 4
MCR42

Main features

MCR41/42(*) is a camera dual true diversity wire-
less-microphone receiver system in a modular stand-
alone or slot-in configuration (compatible with most
camera's slot):
• Extreme RF (radiofrequency) performances and
reliability
• Extreme frequency agility (tuning windows up
to 240 MHz with independet tunables filters
2 ch's):
MCR42-L: 470/678 Mhz (TV ch 21/46)
»
MCR42-h: 590/822 Mhz (TV ch 36/65)
»
(extended range up to 830 available on re-
quest and upon your country-specific regula-
tions)
• digital output on AES3
• multi-companding compatibility
• future digital functionality enhancements
• Automatic scan for best channels, squelch and
other automatic setup
• Infrared interface (i.e. for system setup, micro-
phone programming)
• Automatic transmitter re-programming (thru infra-
red, sync function)
• Push to Talk (PTT) function with additional audio
output signals (patented)
(*) Note MCR41 is the version with only one diver-
sity RX board mounted. It supports all features of
MCR42 and is compatible with MCR42 Firmware.
It is also possible to mount the second Rx board to
upgrade a MCR41 to an MCR42.
dual true diversity receiver
on
