high performances microphone system
B
rief description
The MCR42 is a high performance microphone re-
ceiver suitable for broadcast and high profes-
sional applications.
Thanks to Wisycom movable filter technology,
MCR42 is able to work in a bandwidth up to 240
MHz, still keeping an exceptional selectivity and in-
termodulation immunity.
This miniature design allows to integrate a DUAL
TRUE DIVERSITY receiver while keeping a small
size to fit camera slot in:
- Ikegami/Panasonic (UNISLOT™);
- Philips/Thomson/Grass Valley;
- Sony.
The audio receiver block is fully digital to allow a
better quality, digital output and emulation of most
of companding chipsets. It supports also AES3 au-
dio output with an overall sounds delay below 1.5
msec.
MCR42 is designed to be:
• "easy & quick to use" thanks to automatic setup
functions (i.e. frequencies, squelch, scan), remote
configuration utilities (thru infrared), an OLED dis-
play with intuitive context menu navigation.
• "extremely flexible", with an incredible frequen-
cy agility up to 240 MHz. Moreover the DSP board
allows analogue and digital (AES3) output, with
multi-companding compatibilities and other digital
features.
• "best in class performances", thanks to the lat-
est Wisycom technology the unit has extreme RF
sensitivity and immunity and superb audio quality.
• "a durable & upgradable investment", thanks
to the very robust design (aluminum housing) and
the possibility to upgrade/enhance units perfor-
mances.
Moreover MCR42 system is already set up for the
exclusive PTT function (remote command), devel-
oped and patented by Wisycom and now appreciated
in the broadcast world:
Simply pushing this button (PTT), the pre-
senter causes the remote switching of the
receiver's output-line, from the "main line" to
the additional "intercom line", in order to be
able to talk "off-air" directly with the technical
team. Then all PTT's MICs can be connected
in pre-fading allowing a clever intercom
setup.
t
aBle of contents
BRIEf DESCRIPTIon � � � � � � � � � � � � � � � � � � � 3
Safety instruction . . . . . . . . . . . . . . . . . . . . . . . . 4
Main features . . . . . . . . . . . . . . . . . . . . . . . . . . 4
TEChnICAL DESCRIPTIon � � � � � � � � � � � � � � � 5
USER gUIDE � � � � � � � � � � � � � � � � � � � � � � � � � � 6
FRONT PANEL. . . . . . . . . . . . . . . . . . 6
Display menu . . . . . . . . . . . . . . . . . . 7
MAIN MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
HEADPHONE . . . . . . . . . . . . . . . . . . . . . . . . . . 7
POWER ON . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
EDIT RX1/RX2 . . . . . . . . . . . . . . . . . . . . . . . . . 7
EDIT RX1:GR-Ch . . . . . . . . . . . . . . . . . . . . . . . 7
EDIT RX1: Frequency. . . . . . . . . . . . . . . . . . . . 8
EDIT RX1: Squelch . . . . . . . . . . . . . . . . . . . . . 8
EDIT RX1: Expander . . . . . . . . . . . . . . . . . . . . 8
EDIT RX1: Tone Squelch. . . . . . . . . . . . . . . . . . 8
EDIT RX1: Config (squelch/PTT) . . . . . . . . . . . . . 8
EDIT RX1: Audio Out . . . . . . . . . . . . . . . . . . . . 8
EDIT RX1: Sig. Phase . . . . . . . . . . . . . . . . . . . . 8
EDIT RX1: Scan . . . . . . . . . . . . . . . . . . . . . . . . 8
Rear Panel . . . . . . . . . . . . . . . . . . . . 9
Stand alone socket . . . . . . . . . . . . . . . . . . . . . . 9
Slot in sockets . . . . . . . . . . . . . . . . . 9
SLK 42-IK (Panasonic) . . . . . . . . . . . . . . . . . . . 9
SLK 42-PH (Grass Valley) . . . . . . . . . . . . . . . . . 9
SLK 42-SX (Sony) . . . . . . . . . . . . . . . . . . . . . . 9
Specifications . . . . . . . . . . . . . . . . . 10
CE Declaration . . . . . . . . . . . . . . . . 11
Pag. 3
