EGi DOMOS2 Installer Manual page 6

6 Cables and technical data
Limits
LINE LENGTH
The maximum line length is determined by the voltage drop along the cable. To determine whether or not there is enough voltage in the module, voltage between
2 and 0 wires must be over 13 volts. The voltage drop for 40180 and 40181 cables is based on the following formula:
dV = S x L x l
Where: L means the length of the cable,
S means the conductor section; and
dV means the voltage drop measured in volts, which must be under 3.
The maximum length of the BUS must be 125 m. If you need more cable length, make a "star-shape" installation.
INSTALLATION ELEMENTS
The maximum number of modules supported by an installation will depend on their individual consumption. This consumption will determine the type of power
supply. The intensity along the cable will limit the length of the line, according to the formula of the previous section
intensity of the power supply cables (2 and 0) is 7 A.
central unit (for DIN rail)
central unit (for ø60 mm box)
MAXIMUM POWER OF THE INSTALLATION
The maximum permissible intensity of the power supply cables (2 and 0) is 7 A. Therefore, the maximum power provided by the power supplies will be
105 W.
Make sure you remember to connect the cases of the EGi elements to the ground wire of the installation.
DOMOS2 equipments must be installed according to the ITC-BT-51 norm on "Installation of automation, energy management, building and home
security systems", compliant with the Spanish REBT standard ("Electro-technical Regulations for Low Voltage"), in accordance with RD 842/2002.
Cables
WARNING:
Please be very cautious when
connecting the BUS.
The colours used to distinguish
the conductors do not corres-
pond to the colours used in the
previous DOMOS series.
www.egiaudio.com
consumption (max)
60 mA
40010
40020 100 mA
40040 110 mA
70 mA
40050
40060 150 mA
consumption (max)
45 mA
40070
80 mA
40080
50 mA
40090
70 mA
40200
2
conductor mm function
2 1.50 (+) 15 V= Power supply
0 1.50 Ground
1 0.25 Intercom data line
3 0.25 Intercom audio
4 0.25 Audio
5 0.25 Audio
6 0.25 Audio
7 0.25 Audio
8 0.25 Audio
9 0.25 Audio
+ R 0.75 Loudspeaker output (+)
– R 0.75 Loudspeaker output (common)
+ L 0.75 Loudspeaker output (+) + stand-by amplifier
– L 0.75 Loudspeaker output (common) + stand-by amplifier
control units consumption (max)
40220 195 mA
40221 215 mA
40271 230 mA
40281 235 mA
40300 240 mA
60 mA
40620
interface modules consumption (max)
40410 100 mA
40420 100 mA
40521 250 mA
40530 150 mA
40580 -- -- mA
Cables and technical data
125 m
125 m 125 m
125 m 125 m
125 m
"LINE LENGTH". The maximum permissible
auxiliary modules consumption (max)
20
40140
40310 240
40510 100
40540 150
30
40550
8.7 mA (230 V~)
40550
40610 60
40640 120
40630 30
40650 150
40660 120
voltage programs
15 V=
0 V
Digital signal
3 V audio
3 V audio; +7 V=
3 V audio; +7 V=
3 V audio; +7 V=
3 V audio; +7 V=
3 V audio; +7 V=
3 V audio; +7 V=
3 V audio
3 V audio
3 V audio; +3 V=
3 V audio
mA
mA
mA
mA
mA (15 V=)
mA
mA
mA
mA
mA
-- --
-- --
Intercom
Intercom
1 L
1 R
2 L
2 R
3 L
3 R
-- --
-- --
-- --
-- --
