Symbols and services

Symbols and services
Turned on
Turned off
OK
Cancel
Forward
Backward
Menu key
Menu exit key
Turn the volume up
Turn the volume down
Next memory/program
ACOUSTIC SURVEILLANCE / BABYPHONE
Your control unit will alow you to surveil the zone in which it is installed, so you
can check if your baby is quiet or a sick relative needs help.
REMOTE CONTROL
Remote control of the sound equipment (IR Link output, infrared remote control for
switching on/off and remote control of the user' s sound system from any room that
has a 40271, 40281 or 40300 control unit installed, or with the EGi ref. 40130
and 40100 remote control or with the remote control of the music source itself).
CLOCK
The control units of the installation display the time in stand-by mode.
ALARM CLOCK
The control unit has a built in alarm clock function, which can be used by connecting
the system at a specific time or activating the buzzer.
INTERCOM
DOMOS2 system allows you to communicate with any zone from any room of the
installation.
BELL
All DOMOS2 central units can be easily connected to the doorbell, so a tone will
be generated through the whole EGi installation when the doorbell rings.
Run potential-free direct conductors from the push button of the house to wire
the doorbell connector. Do not put in parallel with the buzzer.
When the door bell rings, a melody will be played in those zones of the installation
in which this service is activated.
CARILLON
Using this service, a musical carillon will play its tune every quarter-hour, half-hour
or hour for the whole installation.
DOOR PHONE
DOMOS2 Door phone function will allow you to answer and open the door when
receiving a call. You may connect to the installation up to 3 different doors (PORT 1,
PORT 2, PORT 3).
General function
Local function
Domotic functions
Audio function
Listen function
Intercom function
Clock
Timer
Alarm clock
Carillon
Talk
TIMER
The control unit with built-in timer will automatically turn off the system after a
maximum time limit of 59 minutes.
DO NOT DISTURB FUNCTION
You may activate the DO NOT DISTURB function to mute any communication from
the bell, entry phone or intercom in the zone where the control unit is installed.
MESSAGE RECORDER FUNCTION
Control units of ref. 40271, 40281 or 40300 have been upgraded with the message
function. Using this service, you may record a voice message (max. 20 seconds).
DOMOTIC FUNCTIONS (DOMOTIC SCENES & LIGHTING ATMOSPHERES)
40271, 40281 or 40300 Control units will enable you to control the connection
or disconnection of home electrical appliances, local thermostat, rolling up/down
the awnings and pulling up/down the blinds.
You will also be able to combine these devices in order to activate/deactivate them
simultaneously at your choice, by just pressing one button (domotic scenes).
40620 + 40550 or 40300 + 40550 Modules will enable you to adjust different
light intensities and control up to 4 lamps at the touch of a button.
THERMOMETER AND THERMOSTAT
40271, 40281 and 40300 Control units can display interior and exterior temperature
(with 40530 module) and control a thermostat in order to reach the desired room
temperature.
SOS FUNCTION
You may alert about a dangerous situation or someone in need of help by pressing
the in-wall control unit or remote control.
INSTALLATION CONTROL THROUGH TELEPHONE
You may control your installation remotely from any mobile or fixed telephone using
40521 module.
Listen
Do not disturb
Surveillance/Baby sitter
Open door phone
Cancel door phone
Messages
SOS Alarm
Fire alarm
Gas alarm
Flooding alarm
Intruder alarm (1 and 2)
Symbols
Miscellaneous
Lighting atmospheres (1,2,3 and 4)
Awning
Blind
Heating
Thermostat
Relay
Press the key
Hold the key
Services
