EGi DOMOS2 Installer Manual page 19

Examples of installations
40410 module will allow you to answer and open the door
phone from any zone of the installation.
This installation includes control units of ref. 40271 and
40281 (with radio) for ø60 mm flush-mounting box.
This installation features 1 or 2 audio programs, acoustic
surveillance of the rooms / babyphone, intercom, audio
input and headphones output in the rooms and message
recorder.
H2
V19A
H28N
V29A
Ø60 mm
box
H2
Impedance
16 Ω
2 conductors
ref. 40750
General line
Ref. 40180 / 40181
40220
40221
40271
40281
40300
40310
H3
Derivation box
V19A
100 x 100 mm
H28N
V29A H3 + H4
Ø60 mm
box
H3
Impedance
16 Ω
Impedance
16 Ω
2 conductors
ref. 40750
Plug-in terminal block
ref. 40170
H3 + H4
40220
40221
40271
40281
40300
40310
H3
H4
H5
H4
V19A
H28N
V29A
Ø60 mm
box
Ø60 mm
box
H4
Impedance
16 Ω
Impedance
16 Ω
2 conductors
ref. 40750
40220
40221
40271
40281
40300
40310
40140
40150
40610
H2
H6
H5... H7
Remaining
rooms
Ø60 mm
box
H5... H7
Remaining
rooms
40610
www.egiaudio.com
19
H1
H7
