14.4 Window structure

From top to bottom, the window will be divided into four parts:
1. Product name
2. Menu field: Menu tree is prompted on this field. ">>" symbol indicates the cursor place.
3. Configuring field: You will configure the parameters in this field. < parameters > indicates the
parameters you can choose and < more...> indicates that there have submenu in the title.
4. Operation command for help
The following table shows the parameters in the brackets.
Command
<ip>
<Route|Bridge>
[1~1999]
[1~65534|-t]
82
Description
An item enclosed in brackets is required. If the item is shown
in lower case bold, it represents an object with special
format. For example, <ip> may be 192.168.1.3.
Two or more items enclosed in brackets and separated by
vertical bars means that you must choose exactly one of the
items. If the item is shown in lower case bold with leading
capital letter, it is a command parameter. For example, Route
is a command parameter in <Route|Bridge>.
An item enclosed in brackets is optional.
Two or more items enclosed in brackets and separated by
vertical bars means that you can choose one or none of the
items.
