PLC Wireless Router
Ethernet Port
Antenna
Button
Software Upgrade
Consumption
Environment Requirements
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Rated Input
EMC and Safety
Compliance
Safety Authentication
Green Standard
Physical Characteristics
Dimension
Weight
2 x RJ45 for 10/100 Ethernet (Auto MDI/MDI-X)
PCB-Antenna x 2
Security: Set the status of device members.
Reset: Restore factory default settings.
WPS: Press this pushbutton for less than 3 seconds to
enable the negotiation of PBC mode. Press this pushbutton
for more than 5 seconds to enable or disable WLAN.
Support software upgrade by Web page.
6.5 W
0~40ºC
-10~70ºC
10%~85%, non-condensing
5%~90%, non-condensing
100~240 V AC, 50/60 Hz
FCC Part 15 Class B, CE
UL
RoHS
L × W × H: 107 mm × 62 mm × 48.5 mm
180 g
- 85 -
F@st Plug 502W
