PLC Wireless Router

WPS Settings

WPS refers to Wi-Fi Protected Setup. You can use the WPS setup function to add a wireless
client to a network, without setting some specific parameters, such as SSID, security mode,
and password. To use this function, a wireless client must support WPS. If the wireless client
does not support WPS, you must manually configure the wireless settings of wireless client,
and ensure that its SSID and other wireless security settings are the same as that of the PLC
wireless router.
Choose Wirelss Setup > WPS on the left pane or click WPS in the WIRELESS SETUP page
to display the following page.
The following table describes parameters in this page:
Field
Wireless SSID
WPS Config State
Enable WPS
Push Button
Input Station PIN
WPS Session State
Caution
If you want to use WPS, you must select the WPA-PSK/WPA2-PSK mode and the
SSID must be broadcasted.
WPS modes contain PBC mode and PIN mode.
Description
Select a wireless SSID from the drop-down list.
It shows the current authentication mode.
Tick this box to enable WPS function.
Click the PBC button in this page, and then click the PBC
button in the configuration utility page of wireless network
card or press the WPS pushbutton on the wireless network
card within 2 minutes to finish WPS configuration.
Enter the PIN code that is generated randomly by the
configuration utility of wireless card.
Display current WPS connection state.
- 41 -
F@st Plug 502W
