National Instruments Measure Data Acquisition User Manual page 40

Option
Channel
Data cells
Add>>
Remove
Number of iterations
Updates per second
Task Name
Description
Advanced
OK
Cancel
Specify the analog output channel on which to generate a signal. You
may only specify one channel at a time.
Specify the source range of the voltage values to write to the digital-to-
analog converter (DAC) for the channel. Either explicitly type the cell
address, or highlight the text in this field and then select a row of cells
or a column of cells on any worksheet in the workbook. Measure
automatically records the address of your selection in this field.
Click this button after specifying a channel and a data cells range.
Click this button to remove any channels or source ranges that you
selected in the list box.
Specify the number of times Measure should iterate through the
waveform that you specified for a channel. If you specify 0 for the
number of iterations, Measure indefinitely iterates through the
waveform until you run another signal generation task on that same
device or until you exit Excel.
Specify the rate at which Measure writes the voltage values to the
DAC. If you specified more than one channel in your channel list, all
channels will have the same update rate.
When you create a new AO task, Measure suggests a unique name for
your new task. You can change the name in the Task name edit box;
However, the name must be unique to the active workbook.
Click on this button to enter a short description of your task. Measure
displays a description of a task below the task list in the DAQ Tasks
dialog box. Also, if you add your task to the DAQ menu, Measure
displays the task description in the Excel status bar at the bottom of its
window when you select the task from the menu.
Click on this button to configure more of the advanced properties for
the analog output task.
Verify configuration and add a new task or update an existing task in
the data acquisition tasks lists. Return to the DAQ Tasks dialog box.
Ignore changes and return to the DAQ Tasks dialog box.
Description
