1. Select preferred duct location (internal blower -
vertical or horizontal, external blower - vertical
only).
additional strengthening is required. Must be
placed inside frameless cabinets.
4. Temporarily position the range hood in the
desired mounting location. Measure and
mark the mounting holes, duct and electrical
locations with a pencil.
NOTE:
duct opening is necessary. If using an external
5. Drill/cut out the required openings for duct and
electrical access; make sure the duct opening
is large enough to apply duct tape.
NOTE: If installing an external blower, cut out a
wires to pass through. Refer to page 8 for
6. Fasten hood onto cabinet with screws provided.
7. Install electrical.
8. Install duct work and duct tape.
10. Power up hood and check for leaks around duct
tape.
15
5. Duct
opening
cutout
duct/silver
tape
3. Add 1x2
wood strips
2. Baffle
filters
