Mounting The Range Hood - Zephyr Cypress AK7836BS Use, Care And Installation Manual

CAUTION: At least two installers are required
due to the weight and size of the hood.
prepare hood. Refer to page 11 for horizontal ducting conversion.
2. Plum and mark center line on wall.
line A.
5. Mark center line of wood board. Center and align top of board with
Wood Board Dimensions
AK7836BS - 33" x 1/2" x 4"
AK7842BS - 39" x 1/2" x 4"
AK7848BS - 45" x 1/2" x 4"
AK7854BS - 51" x 1/2" x 4"
6. Prepare duct pipe and duct cut outs in upper cabinet if needed or
page 8 for dimensions.
7. Prepare electrical wiring and electrical cut outs in upper cabinet if
needed or wall if horizontal electrical hook up is required. Refer to
screws.
9. Further secure hood onto wall through lower body screw holes by
10. Install electrical.
12. Power up hood and check for leaks around duct tape.
WARNING: Electrical wiring must be done by a qualified person(s) in
accordance with all applicable codes and standards. This range hood must be
properly grounded. Turn off electrical power at service entrance before wiring.
B
A
3 5/16"
1 11/16"
16 1/8"
13 5/8"
10
www.zephyronline.com
C/L
wood board
C/L
FIG. 1
21 1/4"
35 1/4" (42", 48", 54")
FIG. 2
4"
16 "
7/8
min
30"
16 7/8"
5 5/16"
