Onboard LAN Features
• Gigabit ethernet controller supports 10/100/1000Mbps
• Fully compliant to IEEE 802.3 (10BASE-T), 802.3u (100BASE-TX)
and 802.3ab (1000BASE-T) standards
• Integrated power management functions
• Supports wire for management
Serial ATA Interface with RAID
• Supports two SATA (Serial ATA) interfaces which are compliant
with SATA 1.0 specification (1.5Gbps interface)
• Supports RAID 0, RAID 1 and JBOD
IEEE 1394 Interface
• VIA VT6307 PCI 1394 integrated host controller
• Supports two 100/200/400 Mb/sec ports
IDE Interface
• Supports ATA/33, ATA/66, ATA/100 and ATA/133 hard drives
Accelerated Graphics Port (A.G.P.)
• Supports AGP 8x up to 2133MB/sec. and AGP 4x up to
1066MB/sec. bandwidth for 3D graphics applications
Rear Panel I/O Ports
• 1 mini-DIN-6 PS/2 mouse port
• 1 mini-DIN-6 PS/2 keyboard port
• 1 DB-9 serial port
• 1 DB-25 parallel por t
• 1 DB-15 VGA port
• 4 USB 2.0/1.1 ports
• 1 RJ45 LAN port
• 1 IEEE 1394 port
• 3 audio jacks: line-in, line-out and mic-in
