DFI K8M800 INFINITY User Manual page 37

2
Hardware Installation
2.5.7 RJ45 Fast-Ethernet Port
RJ45 LAN
The system board is equipped with an onboard RJ45 fast-ethernet
LAN por t at location CN5 of the system board. It allows the
system board to connect to a local area network by means of a
network hub.
BIOS Setting
Enable or disable the onboard LAN in the Integrated Peripherals
submenu ("VIA OnChip PCI Device" section) of the BIOS. Refer to
chapter 3 for more information.
Driver Installation
Install the "VIA LAN Drivers". Refer to chapter 4 for more informa-
tion.
37
