4
Supported Software
4.3 3D Audio Configuration
When you install the audio driver, the 3D Audio Configuration
software will at the same time be installed into your system. 3D
Audio Configuration is an audio panel for setting basic audio
configurations. It allows you to configure 2-channel, 4-channel and 6-
channel audio modes as well as configure the audio effects. After
installing the audio driver and rebooting the system, you can run 3D
Audio Configuration either from the taskbar or from the Control
Panel.
a. Right-click the 3D Audio Configuration icon which you will find in
the taskbar at the lower right corner of the desktop screen.
b. On your Windows desktop, click Start, point to Settings then
click Control Panel. The Control Panel dialog box will appear.
Double-click CMI Audio Config.
Speaker Output
When you open 3D Audio Configuration, the default screen that
appears is the Speaker Output. This is where you will configure
analog output settings to speakers.
S/PDIF
This panel is used to configure S/PDIF output which provides a low-
distortion digital data transfer between audio devices.
Volume Control
This panel provides digital volume control for all 6 channels. You can
regulate each volume to the speaker when playing digital sound
sources.
Microphone
This panel is used to configure the microphone.
114
