1
Introduction
Energy Efficient Design
• Suppor ts ACPI specification and OS Directed Power
Management
• Wake-On-Events include:
-
-
-
-
-
• System power management supported
• CPU stopped clock control
• Hardware supports SMI green mode
• Microsoft
• Soft Power supported - ACPI v1.06 specification
• AC power failure recovery
• CPU Overheat Protection function monitors CPU temperature
and fan during system boot-up
Onboard Graphics Features
• Integrated UniChrome2 3D/2D graphics controller
• Integrated S3 Graphics with 2D/3D acceleration
-
-
-
-
• Supports 2D acceleration features
• Supports 3D acceleration features
Audio Features
• AC'97 2.2 extension compliant codec
• Supports Microsoft
• AC'97 supported with full duplex, independent sample rate
converter for audio recording and playback
• S/PDIF-in/out compressed digital output
• 6-channel audio output via software
8
Wake-On-PS/2 Keyboard/Mouse
Wake-On-USB Keyboard/Mouse
Wake-On-Ring (external modem)
Wake-On-LAN
RTC timer to power-on the system
® ®
/Intel APM 1.2 compliant
Optimized Unified Memory Architecture (UMA)
Supports 16/32/64MB Frame Buffers size
200MHz Graphics Engine Clock
128-bit data buses between north bridge and graphics core
®
DirectSound/DirectSound 3D
