Battery Charging

1. This Product uses a rechargeable Lithium
Polymer battery
2. Use the 30 Pin connector, located on the bottom of DLT
100 to charge the battery. Full charging time: approx.
5 hours Red LED flashes while charging.
Green LED on steady when battery is charged.
3. Battery Maintenance
° Charge the battery at room temperature
° Not recommended to charge the battery more than 12
hours continuously
( Optional CHG 102 - 2-bay charger available )
2-w a y mode
operation guide
POWER ON/OFF
Press and hold the Power/Menu button for 2 seconds.
LED's will flash and the LCD will turn on.
Press and hold the Power/Menu button for 2 seconds to
turn the unit off.
6
FULL DUPLEX (TWO WAY) COMMUNICATION
Any two people can talk in a group at any given time. The
CM will have first priority, CS has second priority and
Slave units have third priority. The CM or CS will have to
turn off their talk access to allow the Slave units to talk.
When two people are talking in a group the participants
can hear both voices in the DLT's or DLR's.
The CM and CS have the ability to lock out other talkers
by holding down the TALK button for three seconds.
All system TALK LEDs will continuously flash while other
participants are locked out of the TALK feature.
ELECTRONIC VOTING
The CM must press and hold the ABS button until the
LED turns on. This will activate the voting feature in the
system. Participants with DLT 100's can press the NO or
YES button and the count will be displayed on the CM unit
LCD. Participants can change their vote and the count
will change on the CM unit, but they cannot vote more
than once. No votes will show on the left side of the LCD
and YES votes on the right side. ABS will not be counted.
The CM must press and hold the ABS button again to
exit the voting mode. When in voting mode, only the CM
can talk in the system. Addresses 0 - 99 must be used for
voting feature. Addresses over 99 will not be registered.
NOTE: IF CM is turned off every DLT that is synched will
automatically turn off in 5 seconds.
ATTENDEE CHECKING
When the Master Chairman presses the MENU button
once, the number of SLAVE devices connected to the
system will be displayed for two seconds.
Addresses 0 - 99 must be used for attendee checking
feature. Addresses over 99 will not be registered. ie: C 12
= 12 DLT's synched with CM
ADDRESS CONFIRMATION
Press the MENU button twice for the CM and CS, once
for SLVs. The address for the DLT 100 will be displayed for
two seconds. NOTE: Every DLT 100 MUST have its own
address and all must be assigned to the same group.
TIMER FUNCTION
The CM has the ability to set a talk timer from 0 to 60
minutes. The factory default is 0. This timer will allow the
TALK feature on SLAVE units to have only a selected
amount of time to talk. 0 means there is no talk time limit
and speak time is unlimited.
