- Page 1 Digi-Wave 300 Series ™ DLT 300 Digital Transceiver and DLR 360 Digital Receiver USER MANUAL DLT 300 DLR 360 The Digi-Wave 300 Series is not backward compatible with previous Digi-Wave transceivers or receivers. MAN 195C...
-
Page 2: Table Of Contents
DigiWave 300 Series Digital Transceiver and Receiver Digi-Wave™ 300 Series DLT 300 Digital Transceiver and DLR 360 Digital Receiver Contents Safety Warnings and Recycling Instructions ..........................3 System Overview ..................................4 DLT 300 Controls and Connectors ............................5 DLT 300 Operation .................................. 5 Button Functions ................................ -
Page 3: Safety Warnings And Recycling Instructions
Please take the batteries to a retail or community collection point for recycling. Product Recycling: Please do NOT dispose of your Williams Sound equipment in the household trash. Please take the equipment to an electronics recycling center or return the product to the factory for proper disposal. -
Page 4: System Overview
Note: for simplicity, throughout the rest of this manual, the DLT 300 may be referred to as a “DLT” and the DLR 360 may be referred to as a “DLR”. Similarly, Master 1, Master 2 and Guest may be referred to as “M1”, “M2”, and “GST”. The Digi-Wave 300 Series is not backward compatible with previous Digi-Wave transceivers or receivers. -
Page 5: Dlt 300 Controls And Connectors
DigiWave 300 Series Digital Transceiver and Receiver DLT 300 Controls and Connectors INTERNAL SPEAKER LCD DISPLAY LED INDICATORS TALK BUTTON WITH RAISED BRAILLE DOT VOLUME / SELECT UP VOLUME / SELECT DOWN POWER / MENU HEADPHONE JACK 3.5 MM MICROPHONE JACK 3.5 MM INTERNAL MICROPHONE DOCKING / CHARGING CONNECTOR 30-PIN... - Page 6 DigiWave 300 Series Digital Transceiver and Receiver MICROPHONE LEVEL ADJUSTMENT · Hold the button for two seconds to enter mic level adjustment. For level adjustment use LINE LEVEL ADJUSTMENT · Hold the button for two seconds to enter mic level adjustment. For level adjustment use TONE ADJUSTMENT ·...
-
Page 7: Dlr 360 Controls And Connectors
DigiWave 300 Series Digital Transceiver and Receiver CHARGING/ DOCKING DLR 360 Controls and Connectors CONNECTOR 30-PIN HEADPHONE LANYARD SLOT SPEAKER JACK 3.5 MM STRENGTH DLT NO. 1 STRENGTH DLT NO. 2 ANTENNA SYMBOL NUMERIC TYPE BATTERY NUMERIC DISPLAY STRENGTH RED LED GREEN LED VOLUME ADJUST CHANNEL/... -
Page 8: Getting Started: Preprogrammed Systems
DigiWave 300 Series Digital Transceiver and Receiver Getting Started: Preprogrammed Systems If a system has been purchased, you should not need to perform any programming. The system will have been configured to your order. Turn Master 1 on first so other units can pair. Guest units will turn off after 5 minutes if they cannot find a master. 1. -
Page 9: Before Programming The Digi-Wave™ System
DigiWave 300 Series Digital Transceiver and Receiver Before Programming the Digi-Wave™ System Depending upon the mode chosen, up to six people can talk in a group at any given time. The M1 will have first priority, M2 has second priority and Guest units have third priority. When two or more people are talking in a group, the participants can hear their voices with the DLTs or DLRs. - Page 10 DigiWave 300 Series Digital Transceiver and Receiver Rules of Operation (1-way modes) The following rules must be followed when setting up any Digi-Wave™ system. Failure to adhere to these rules will result in unpredictable, unsupported operation. • Up to 15 channels can be used simultaneously, i.e. one floor and 14 interpreters. •...
-
Page 11: Programming The Digi-Wave™ System For 1-Way Modes
DigiWave 300 Series Digital Transceiver and Receiver Programming the Digi-Wave™ System for 1-way Modes There are 4 basic steps to programming a Digi-wave system: Set Mode: 2-way or 1-way Set Priority: Master 1, Master 2, and Guest Set Channel Set Group Number Most of the programming is done on the DLT(s);... -
Page 12: Programming The Digi-Wave™ System For 2-Way Modes
DigiWave 300 Series Digital Transceiver and Receiver Programming the Digi-Wave™ System for 2-way Modes There are 4 basic steps to programming a Digi-wave system: Set Mode: 2-way or 1-way Set Priority: Master 1, Master 2, and Guest Set Address Set Group Number Most of the programming is done on the DLT(s);... -
Page 13: Programming The Digi-Wave™ System: Optional Settings
DigiWave 300 Series Digital Transceiver and Receiver Programming the Digi-Wave™ System: Optional Settings DLT Secure Key Code: When a group has been set up and the same Secure Code has been entered into all the DLTs, the DLTs without this Secure Original (save) Code entered cannot listen in on the group. - Page 14 DigiWave 300 Series Digital Transceiver and Receiver DLT Attendee Checking When the M1 presses the MENU button once, the number of Guest devices connected to the system will be displayed for two seconds. Addresses 0 - 99 must be used for attendee checking feature. Addresses over 99 will not be registered. ie: C 12 = 12 DLTs synched with M1.
- Page 15 Original (save) Secure Key Code fig. 1 Secure DigiWave 300 Series Digital Transceiver and Receiver 3. Use either of the -/+ buttons to choose between Stt:0 (Off), St:1 (-6dB) (default), or St:2 (-12dB). 4. Press and hold the Up button and the Down button simultaneously for 2 seconds to exit Secure Key Code fig.
-
Page 16: Example 1: 2-Way Mode, Tour Guide
DigiWave 300 Series Digital Transceiver and Receiver Example 1: 2-way Mode, Tour Guide HOW IT WORKS 1. Tour Guide 1 speaks, using a DLT alone (built-in mic) or using it with a compatible headset mic. 2. Each Tour Group Member and Tour Guide 2 listen directly to Tour Guide 1, each using a DLT alone (built-in speaker) or using it with a compatible headset mic. -
Page 17: 2-Way Setup For Tour Guide Operation
DigiWave 300 Series Digital Transceiver and Receiver Original (save) TOUR GROUP TOUR GUIDE 1 TOUR GUIDE 2 Intercom Setup: Master Unit Guest Unit(s) 2-WAY 2-WAY 2-way Tour Guide Setup: Tour Guide 1 Unit Tour Guide 2 Unit Tour Group Member Units A558 2-WAY SETUP FOR TOUR GUIDE OPERATION 1-way Modes... - Page 18 DigiWave 300 Series Digital Transceiver and Receiver 2-way Tour Guide Setup Press and hold POWER Press and Hold The other icons will disappear Use the buttons button for 2 seconds for 3 seconds to enter and the current mode icon to change to 2-way Tour to turn DLT ON programming mode.
-
Page 19: Example 2: Simultaneous Interpretation (1-Way)
See section “Repeater Mode” for details. The 3.5mm stereo microphone jack can accept a headphone level or a line level output from audio sources when using the Williams Sound WCA 094 attenuated cable. ALL INTERPRETERS ARE LISTENING TO... -
Page 20: 1-Way Setup For Simultaneous Interpretation
DigiWave 300 Series Digital Transceiver and Receiver 1-WAY SETUP FOR SIMULTANEOUS INTERPRETATION 1-way Modes 2-way Modes 1-way 1-way Speak Only Receive / Speak 1-way 1-way 2-way 2-way (Main Speaker) (Interpreter) Repeater Receive Only Intercom (Tour Guide) 1-way Simultaneous Interpretation Setup 1-way Modes 2-way Modes 1-way... -
Page 21: Example 3: Intercom (2, 3, 4, 5 Or 6 Simultaneous Talkers)
How it Works: 6-way Intercom DigiWave 300 Series Digital Transceiver and Receiver Example 3: Intercom (2, 3, 4, 5 or 6 simultaneous talkers) HOW IT WORKS 1. There must be one primary “Master 1” unit per group (for synchronization). 2. Each secondary unit is set up as a “Guest”. 3. -
Page 22: 2-Way Setup For Intercom
DigiWave 300 Series Digital Transceiver and Receiver 2-WAY SETUP FOR INTERCOM 1-way Modes 2-way Modes 1-way 1-way Speak Only Receive / Speak 1-way 1-way 2-way 2-way (Main Speaker) (Interpreter) Repeater Receive Only Intercom (Tour Guide) Intercom Mode Setup 1-way Modes 2-way Modes 1-way 1-way... -
Page 23: Example 4: Repeater Mode
DigiWave 300 Series Digital Transceiver and Receiver 1-way Modes 2-way Modes 1-way 1-way Example 4: Repeater Mode Speak Only Receive / Speak 1-way 1-way 2-way 2-way (Main Speaker) (Interpreter) Repeater Receive Only Intercom (Tour Guide) An additional DLT 300 can be set-up as a repeater to increase the range of each channel. To use Repeater Mode, first get the System set up using instructions under Example 2 for Simultaneous Interpretation. - Page 24 DigiWave 300 Series Digital Transceiver and Receiver ORIGINAL (SAVE) Any DLT’s in 1-way Modes, or DLR’s, must be in the same Group. Each Listener would select a desired channel/language. See below - when repeater mode is used, the main speaker’s unit is reconfigured as a Guest unit. The Repeater is configured as the Master unit.
-
Page 25: Differences Between Dlt 300, Dlt 100 2.0 And Dlt 100
DigiWave 300 Series Digital Transceiver and Receiver Differences between DLT 300, DLT 100 2.0 and DLT 100 Function/Description DLT 300 DLT 100 2.0 DLT 100 With settings locked, can adjust With settings locked, can ONLY With settings locked, can ONLY adjust SLOC Power, Volume, Talk, Tone, Mic adjust Power, Volume, Talk... -
Page 26: Differences Between Dlr 360, Dlr 60 2.0 And Dlr 60
DigiWave 300 Series Digital Transceiver and Receiver Differences between DLR 360, DLR 60 2.0 and DLR 60 Between 08/13 and 11/13, a limited number of DLR 60’s were manufactured and sold to the marketplace. If the front of the unit says “Digi·WAVE”, you have a DLR 60. -
Page 27: Specifications
DigiWave 300 Series Digital Transceiver and Receiver Specifications DLT 300 TRANSCEIVER Dimensions 103.3 x 61.8 x 11.3 mm (4.07 x 2.43 x 0.44 inches) (H x W x D) Weight 82 g (2.9 oz) including battery Color Black/Silver (Front/Back) Case Material Black ABS plastic Battery type Lithium Polymer with smart charge built into transceiver;... -
Page 28: Dlr 360 Receiver
DigiWave 300 Series Digital Transceiver and Receiver NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE. DLR 360 RECEIVER Dimensions: 2.36” W x 3.54” H x 0.63” D (60 mm x 90 mm x 16 mm) Weight: 1.7 oz. (47g) without batteries. Frequency Band: 2.4 GHz (ISM band) Modulation: FSK Multi Channel: Up to 15 simultaneous channels (one way mode) -
Page 29: Testing And Certification
DigiWave 300 Series Digital Transceiver and Receiver Testing and Certification These units have been tested and certified by an independent party, Anatel, in Brazil. Troubleshooting PROBLEM CAUSE WHAT TO DO Power does not turn-on Dead battery Charge the battery, replace battery Power turned off Master device can’t be found Turn on Master unit... -
Page 30: Faqs
DLT – up to 14 hrs per charge. DLR - up to 24 hrs (2 x AAA Alkaline batteries) or 18 hrs (2 x AAA NiMH batteries). Is this product compatible with any other competitive system? Where can I buy this product? Through Williams Sound dealers. -
Page 31: Fcc Statements
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement. Visit the Williams Sound website for the current declarations of conformity and latest list of certifications at http://www. williamssound.com. -
Page 32: 2-Year Warranty
No person has any authority to bind Williams Sound to any representation or warranty with respect to the DLT 300 and DLR 360.
