· Applications include Tour Guide, Team Teach,
Wireless Intercomm, Portable Discussion and
Personal Communication systems
SIMULTANEOUS INTERPRETATION
· Can accommodate floor (or common) language, plus
up to 14 simultaneous languages
· DLT 100 has repeater function for increased range in
interpretation mode
100
DL T

button functions

POWER / MENU BUTTON
° Press and hold for power On/Off
° Press once to change section when in setup menu
VOTING / SETTING BUTTON
° Press No -Yes button together to enter or exit setup menu
° Use [YES],[NO], or [ABS] in voting mode
° Use these buttons to select channels in simultaneous
interpretation mode
° Press and hold [ABS] button to enter voting mode.
Master unit controls voting function. All votes viewable
only on Chairman Master and Chairman Slave unit. Must
have address assigned between 1 — 99 to allow voting
or attendance function
MICROPHONE LEVEL ADJUSTMENT
° Hold [ NO ] button for two seconds to enter mic level
adjustment. For level adjustment use [ - ] or [ + ]
VOLUME CONTROL / SELECT BUTTON
° Control / Volume
° Use to navigate selection in setup menu.
TALK BUTTON
° Press button once to activate the microphone.
Press button once more to turn off the microphone
° Press and hold the button for approximately 2 seconds
to mute other DLT 100 slave units. Only the CM and CS
have this function. ( [ TALK ] LED will blink on all units
when in mute mode ).
Internal Speaker
LCD display
LED Indicator
Talk Button
Volume / Select Up
Volume / Select Down
Power / Menu
Ext. Headphone
Jack 3.5
mm
Ext. Mic Jack 3.5 mm
Int. Microphone
30-pin Connector
5
