ASSEMBLY

• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you complete all assembly steps.
• To identify small parts, see page 5.
1. Orient the Rear Stabilizer (14) as shown.
Tighten the two Leveling Feet (50) into the
underside of the Rear Stabilizer (14).
While a second person lifts the rear of the
Frame (1), insert the Rear Stabilizer (14) into the
Frame.
Attach the Rear Stabilizer (14) with four M8 x
60mm Screws (43).
2. Orient the Front Stabilizer (2) as indicated by the
sticker.
While a second person lifts the front of the
Frame (1), attach the Front Stabilizer (2) to the
Frame with two M10 x 80mm Screws (36).
• In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
one adjustable wrench
Assembly may be easier if you have a set of
wrenches. To avoid damaging parts, do not use
power tools.
1
14
50
50
2
6
1
43
36
2
1
