Model No. PFEVEX73012.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal (under frame)
QUESTIONS?
If you have questions, or if there are
missing parts, please contact us:
UNITED KINGDOM
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
CASTLEFORD
WF10 5QJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 225 ZLX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-Form 225 ZLX

Summary of Contents for Pro-Form 225 ZLX

  • Page 1 Model No. PFEVEX73012.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal (under frame) QUESTIONS? If you have questions, or if there are missing parts, please contact us: UNITED KINGDOM Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    The ance, and toning the body. The 225 ZLX exercise bike model number and the location of the serial number provides a selection of features designed to make your decal are shown on the front cover of this manual.

  • Page 5: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.

  • Page 6: Assembly

    ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tools: • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you complete all assembly steps.
  • Page 7 3. Orient the Upright (3) as shown. Have a second person hold the Upright near the Frame (1). Locate the wire tie in the lower end of the Upright Wire Tie (3). Tie the wire tie to the Main Wire (31). Then, pull the upper end of the wire tie until the Main Wire is routed through the Upright.
  • Page 8 5. Orient the Top Shield (9) as shown. Slide the Top Shield onto the Upright (3). Attach the Top Shield (9) to the Frame (1) with two M4 x 16mm Screws (40). Orient the Top Shield Cap (10) as shown. Press the Top Shield Cap onto the Left and Right Shields (17, 18).
  • Page 9 7. Loosen and remove the Seat Knob (11) from the Seat Carriage (30). Look underneath the Seat (12), and locate the Carriage Block (55) inside the Seat Carriage (30). Orient the Seat Post (5) as shown. Set the Seat Carriage (30) in the bracket on the Seat Post. Next, insert the Seat Knob (11) upward through the bracket on the Seat Post (5) into the hole in the Carriage Block (55).
  • Page 10 9. Hold the Console Plate (19) near the Upright (3). Insert the Main Wire (31) upward through the Console Plate. Next, insert the Console Plate (19) into the Upright (3), and align the indicated large holes. Large Holes 10. Have a second person hold the Handlebar (47) near the Upright (3).
  • Page 11 11. The Console (6) can use four D batteries (not included); alkaline batteries are recommended. Do not use old and new batteries together or alkaline, standard, and rechargeable batter- ies together. IMPORTANT: If the Console has been exposed to cold temperatures, allow Battery Cover it to warm to room temperature before you...
  • Page 12 13. Attach the Water Bottle Holder (49) to the Upright (3) with two M4 x 22mm Screws (54). 14. Identify the Right Pedal (26), which is marked with an “R.” Using an adjustable wrench, firmly tighten the Right Pedal clockwise into the Right Crank Arm (59).

  • Page 13: How To Use The Exercise Bike

    HOW TO USE THE EXERCISE BIKE HOW TO LEVEL THE EXERCISE BIKE HOW TO ADJUST THE SEAT POST If the exercise bike For effective exercise, the seat should be at the proper rocks slightly on your height. As you pedal, there should be a slight bend in floor during use, turn your knees when the pedals are in the lowest position.
  • Page 14 CONSOLE DIAGRAM FEATURES OF THE CONSOLE For example, lose unwanted pounds with the 8-week Weight Loss workout. iFit workouts control the resis- The advanced console offers an array of features tance of the pedals while the voice of a personal trainer designed to make your workouts more effective and coaches you through your workouts.
  • Page 15 HOW TO USE THE MANUAL MODE Profile—When a workout is selected, this display mode will show a profile of the resistance settings 1. Turn on the console. of the workout. Pulse—This display mode will show your heart rate Press any button or begin pedaling to turn on the console.
  • Page 16 5. Measure your heart rate if desired. If your heart rate is not shown, make sure that your hands are positioned as described. Be careful not If there are sheets of to move your hands excessively or to squeeze the plastic on the metal contacts tightly.
  • Page 17 HOW TO USE A PRESET WORKOUT As you exercise, keep your pedaling speed near the goal 1. Turn on the console. speed for the current seg- ment. The goal speed will Press any button or begin pedaling to turn on the appear in the display when console.
  • Page 18 HOW TO USE AN IFIT WORKOUT HOW TO USE THE SOUND SYSTEM iFit cards are available separately. To purchase iFit To play music or audio books through the console cards, go to www.iFit.com or see the front cover of this sound system while you exercise, plug your audio manual.

  • Page 19: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise bike regu- Next, locate the Reed Switch (21). Loosen, but do not larly. Replace any worn parts immediately. remove, the M4 x 16mm Screw (40). To clean the exercise bike, use a damp cloth and a small amount of mild soap.
  • Page 20 HOW TO ADJUST THE DRIVE BELT Tip: It may be necessary to remove the right pedal. Using an adjustable wrench, turn the right pedal coun- If you can feel the pedals slip while you are pedaling, terclockwise and remove it. even when the resistance is adjusted to the highest level, the drive belt may need to be adjusted.

  • Page 21: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 22: Part List

    PART LIST Model No. PFEVEX73012.0 R0412A Key No. Qty. Description Key No. Qty. Description Frame M10 x 50mm Screw Front Stabilizer Resistance Cable Upright M4.2 x 16mm Screw Stabilizer Cap M10 x 80mm Screw Seat Post M8 Locknut Console M10 x 41mm Screw Flywheel Assembly M8 x 20mm Bolt Left Crank Arm...

  • Page 23: Exploded Drawing

    EXPLODED DRAWING Model No. PFEVEX73012.0 R0412A 43 43...

  • Page 24: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) • the name of the product (see the front cover of this manual) • t he key number and description of the replacement part(s) (see the PART LIST and the EXPLODED DRAWING near the end of this manual) RECYCLING INFORMATION This electronic product must not be disposed of in municipal waste.
