ASSEMBLY
• To hire an authorized service technician to
assemble this product, call 1-800-445-2480.
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you fi nish all assembly steps.
• Left parts are marked "L" or "Left" and right parts
are marked "R" or "Right."
1. Go to www.proformservice.com/registration
on your computer and register your product.
• activates your warranty
• saves you time if you ever need to contact
Customer Care
• allows us to notify you of upgrades and offers
Note: If you do not have Internet access, call
Customer Care (see the front cover of this
manual) and register your product.
2. Identify the Rear Stabilizer (3), which has a
Leveling Foot (28) near each end.
Set a sturdy piece of packing material (not
shown) under the rear of the Frame (1).
Orient the Rear Stabilizer (3) as indicated by the
sticker. Attach the Rear Stabilizer to the Frame
(1) with two M10 x 68mm Screws (44).
Then, remove the packing material.
• To identify small parts, see page 6.
In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
one adjustable wrench
Assembly may be easier if you have a set of
wrenches. To avoid damaging parts, do not use
power tools.
1
2
3
28
44
28
7
1
