Pro-Form 225 ZLX User Manual page 10

9. Hold the Console Plate (19) near the Upright (3).
Insert the Main Wire (31) upward through the
Console Plate.
Next, insert the Console Plate (19) into the
Upright (3), and align the indicated large holes.
10. Have a second person hold the Handlebar (47)
near the Upright (3).
Locate the Pulse Wire (52) in the Handlebar
(47). Insert the Pulse Wire into the large hole in
the Upright (3), and then pull the Pulse Wire out
of the top of the Console Plate (19).
Attach the Handlebar (47) and the Console
Plate (19) to the Upright (3) with two M8 x 25mm
Screws (44) and two M8 Curved Washers (57).
9
10
47
44
10
31
19
Large Holes
3
19
52
57
3
