13. Attach the Water Bottle Holder (49) to the

Upright (3) with two M4 x 22mm Screws (54).

14. Identify the Right Pedal (26), which is marked

with an "R." Using an adjustable wrench, firmly

tighten the Right Pedal clockwise into the Right

Crank Arm (59).

Tighten the Left Pedal (not shown) counter-

clockwise into the Left Crank Arm (not shown).

Adjust the strap on the Right Pedal (26) to the

desired position, and press the end of the strap

onto the tab on the Right Pedal. Adjust the

strap on the Left Pedal (not shown) in the

same way.

15. Make sure that all parts of the exercise bike are properly tightened. Note: Some hardware may be left

over after assembly is completed. To protect the floor or carpet from damage, place a mat under the exercise

bike.

Strap

Tab
