3. Orient the Upright (3) as shown. Have a second
person hold the Upright near the Frame (1).
Locate the wire tie in the lower end of the Upright
(3). Tie the wire tie to the Main Wire (31). Then,
pull the upper end of the wire tie until the Main
Wire is routed through the Upright.
Tip: To prevent the Main Wire (31) from fall-
ing into the Upright (3), secure the Main Wire
with the wire tie.
4. Tip: Avoid pinching the Main Wire (31). Set
the Upright (3) on the Frame (1).
Attach the Upright (3) with four M8 x 25mm
Screws (44) and four M8 Split Washers (45).
Tip: Start all the Screws before fully tighten-
ing them.
3
4
Avoid pinching the
Main Wire (31)
7
Wire Tie
3
31
Wire Tie
1
31
3
44
44
45
45
1
