TOOLS

Special Tools
PART NUMBER
2870390
PA-45153
PA-49959
PA-47344
PA-49935
PA-49936
SPX Corp: 1-800-328-6657 or http://polaris.spx.com/
TOOL DESCRIPTION
Piston Support Block
Flywheel Puller
Transmission Output Shaft
Collar Tool
Balance Shaft Slotted Nut
Socket
Crankshaft Slotted Nut
Socket
Flywheel Puller Adaptor
(Use with PA-45153)
9923983 - 2012-2013 RZR 170 Service Manual
© Copyright 2012 Polaris Sales Inc.

TORQUE SPECIFICATIONS

Engine Torque Specifications

TORQUE SPECIFICATIONS
Fastener
Camshaft Chain Guide
Pivot Bolt
Camshaft Chain
Tensioner
Chain Tensioner Cap
Carburetor Intake
Cylinder/Head Nuts
Cylinder Base Screws
Crankcase (inner)
Crankshaft Slotted Nut
Balancer Shaft Nut
Exhaust Nuts
Flywheel Nut
Cooling Fan
Oil Drain Bolt
Oil Pump 
Screws
Oil Pump Sprocket Nut
Oil pump baffle plate
Stator Assembly
Stator Housing
Valve Cover
Valve Adjuster Lock Nut 5mm
Starter Motor
Spark Plug
Pulse Coil Screws
ENGINE
Thread ES35C
Size ft-lbs (Nm)
6mm 5-7 (7-9 Nm)
6mm 5-7 (7-9 Nm)
6mm 5-7 (7-9 Nm)
6mm 7-8 (9-11 Nm)
10mm 18 (25 Nm)
6mm 5-7 (7-9 Nm)
6mm 14-15 (19-21 Nm)
14mm 43 (58 Nm)
14mm 43 (58 Nm)
6mm 7-8 (9-11 Nm)
14mm 43 (58 Nm)
6mm 4-5 (5-7 Nm)
14mm 18 (25 Nm)
6mm 4-5 (5-7 Nm)
6mm 7-8 (9-11 Nm)
6mm 4-5 (5-7 Nm)
6mm 7-8 (9-11 Nm)
6mm 7-8 (9-11 Nm)
6mm 7-8 (9-11 Nm)
4-5 (5-7 Nm)
6mm 5-7 (7-9 Nm)
12mm 11 (15 Nm)
5mm 4-5 (5-7 Nm)
