Rear Wheel Exploded View
Wheel Removal
1. Position the vehicle on a level surface.
2. Set the parking brake and stop the engine.
3. Loosen the wheel nuts slightly. If wheel hub removal
is required, remove the cotter pin and loosen the
castle nut slightly.
4. Elevate the front or rear end of the vehicle off the
ground placing a suitable stand or floor jack under the
frame.
CAUTION
Severe injury could occur if machine tips or falls.
5. Remove the wheel nuts and remove the wheel.
6. If removing the hub, take off the castle nut and
washers(s).
