GENERAL INFORMATION
MISCELLANEOUS SPECIFICATIONS
AND CHARTS

Standard Bolt Torque Specification

Grade 2
Bolt Size
1/4-20
1/4-28
5/16-18
5/16-24
3/8-16
3/8-24
7/16-14
7/16-20
1/2-13
1/2-20

Metric Bolt Torque Specification

Bolt Size 4.6
M3 .3/.5
M4 .8/1.1
M5 1.5/2.5
M6 3/4
M8 7/9.5
M10 14/19
M12 26/35
M14 37/50
M16 59/80
M18 81/110
1.10
Grade 8
Grade 5
Grade 2
ft-lbs (Nm)
5 (7)
6 (8)
11 (15)
12 (16)
20 (27)
23 (32)
30 (40)
35 (48)
50 (69)
55 (76)
4.8
.5/.7
1/1.5
2/3
4/5.5
10/13
18/25
33/45
55/75
85/115
118/160
