FUEL SYSTEM
Crankcase Ventilation System
HOSE - INTAKE VALVE TO OIL SEPARATOR
OIL SEPARATOR
DUAL INTAKE VALVE
HOSE - VALVE COVER
TO OIL SEPARATOR
HOSE-TO AIR FILTER BOX
HOSE - INTAKE VALVE TO CRANKCASE
NOTE: The
crankcase
ventilation
system
is
sensitive to excessive engine oil volume. Never
over-fill the oil level in the engine. Doing so may
cause oil to accumulate inside the airbox.
4.14
9923983 - 2012-2013 RZR 170 Service Manual
© Copyright 2012 Polaris Sales Inc.
