8. For Ductless (recirculating) installations
Install one charcoal filter (available as an extra kit).
9. Connect the molex plug to the electronic box.
10. Fix all available nuts on the internal side of each
duct cover section (square slots).
Rectangular
slots
Duct internal
side
Nut
11. Assemble top duct covers (those with ductless
recirculating slots).
Fix each other with 6 screws (3 per side).
TOP DUCT COVERS
13
www.zephyronline.com
PLAN
DIAGRAM
NUTS
