Terminology & Component Overview
ElliptiGO Arc Model
The picture below gives an overview of the components which make up the
ElliptiGO Arc product. These names will be referred to throughout the
owner's manual.
1 FRAME
2 PRELOAD COLLAR
3 STEERING EXTENDER
4 STEM
5 GRIP
6 HANDLEBAR
7 SHIFTER
8 BRAKE LEVERS
9 CONTROL CABLES
10 FRONT BRAKE
11 FRONT WHEEL QUICK RELEASE
12 FRONT WHEEL
13 TIRE
14 SWING ARM
15 DRIVE ARM
16 FOOT PLATFORM ASSEMBLY
17 CHAINRING GUARD
18 CHAINRING
19 CHAIN
20 REAR DERAILLEUR
21 CASSETTE
22 REAR WHEEL
23 REAR TIRE
24 REAR QUICK RELEASE
25 KICKSTAND (HIDDEN)
26 CHAIN KEEPER
27 CRANK ARM
28 FOOT PLATFORM
29 TOE CAGE (OPTIONAL ACCESSORY)
24
25
23
22
18
20
19
21
4
1
29
28
27
26
17
16
15
5
6
7
8
3
2
14
12
II
9
10
11
