Brakes

Your elliptical bike comes equipped with front and rear rim brakes
actuated by hand levers attached to the handlebars. One lever actuates
the front brake and the other actuates the rear brake. The brakes are
comprised of the following components:
1. Left brake pad
2. Left caliper
3. Brake noodle
4. Quick release bracket
5. Brake cable boot
6. Brake cable
7. Right caliper
8. Right brake pad
3
2
1
4
5
6
7
8
