Summary of Contents for ElliptiGO Arc 24
- Page 1 Arc 24 Addendum to ElliptiGO Owner’s Manual for Processes Specific to the Arc 24...
- Page 2 Terminology & Component Overview The Arc 24 utilizes a 24 speed drivetrain consisting of an 8-speed rear derailleur system in series with a 3-speed internally geared hub. The 3 speed hub and 8 speed rear deraileur are controlled via the left and right hand shifters respectively.
- Page 3 Gear Selection – Internally Geared Hub and Trigger Shifter There are two gear selector units on the Arc 24. There is one on the left side of the handlebars that operates the internally geared hub (3-speed) and has two trigger mechanisms. The upper thumb lever decreases resistance (3-2-1) and the lower thumb lever increases resistance (1-2-3).
- Page 4 For instructions on how to adjust the derailleur, please see the section in the owner’s manual. For a video visit https://youtu.be/Jxffaz-HIhk Place the Arc 24 on the kickstand. 2. Using the LEFT side shifter mechanism, shift into 2nd gear.
- Page 5 Arc 24 Rear Wheel Removal To remove the rear wheel on the Arc 24, follow these steps or for a video visit https://youtu.be/ndH_XvXoWxw Place the bike on the kickstand. 2. While standing on the right side of the bike, lean the bike towards the kickstand to lift the rear wheel off the ground slightly.
- Page 6 Arc 24 Rear Wheel Installation To install the rear wheel on the Arc 24, follow these steps or for a video visit https://youtu.be/g2DfPwueajw Place the bike on the kickstand, or leaning on its side. 2. Ensure the gear selector lever for the internally geared hub...
